KS0068B-00 Datasheet

  • KS0068B-00

  • 16COM/60SEG DRIVER & CONTROLLER FOR DOT MATRIX LCD

  • 22頁

  • SAMSUNG   SAMSUNG

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

KS0068B
16COM/60SEG DRIVER & CONTROLLER FOR DOT MATRIX LCD
INTRODUCTION
100 QFP
The KS0068B is a dot matrix LCD driver & controller LSl which is
fabricated by low power CMOS technology.
FUNCTION
鈥?/div>
Character type dot matrix LCD driver & controller
鈥?/div>
Internal driver: 16 common and 60 segment signal output.
鈥?/div>
Display character format; 5 7 dots + cursor, 5 10 dots + cursor
鈥?/div>
Easy interface with a 4-bit or 8-bit MPU
鈥?/div>
Display character pattern:
5 7 dots format: 192 kinds, 5 10 dots format: 32kinds
鈥?/div>
The special character pattern can be programmable by
Character Generator RAM directly.
鈥?/div>
A customer character pattern can be programmable by mask
option (KS0068B-00; Standard type)
KS0068B-00
English, Japanese
Numberal
鈥?/div>
Automatic power on reset function.
鈥?/div>
It can drive a maximum 80 characters by using the kS0065B
or KS0063B, KS0068B externally.
鈥?/div>
It is possible to read both Character Generator and Display
Data RAM from MPU.
FEATURES
鈥?/div>
Internal Memory
- Character Generator ROM: 8320bits
- Character Generator RAM: 512 bits
- Display Data RAM: 80 8bits for 80 digits.
鈥?/div>
Power Supply Voltage; +5V
盲
10%, +3V
盲
10%
鈥?/div>
Supply voltage for display: 0~-5V(V
5
)
鈥?/div>
CMOS process
鈥?/div>
1/8 duty, 1/11 duty or 1/16 duty: selectable
(1/8 duty; 5 7 dots format 1 line, 1/11 duly; 5 x 10 dots format I line,
1/16 duty: 5 7 dots format 2 line)
鈥?/div>
100 QFP or bare chip available.
