JQC-7FD
SUBMINIATURE HIGH POWER RELAY
Features
1A & 1C configuration
High performance / Low profile
Dielectric strength coil to contacts 2500V
File No.:E133481
VDE 0631 / 0700
Flammability class according to UL94,V-0
File No.: 40008374
CTI 250
CONTACT DATA
Contact Arrangement
Initial Contact
Resistance
Contact Material
Contact Rating
Max. switching voltage
Max. switching current
Max. switching power
Mechanical life
Electrical life
2500VA 300W
10A / 250VAC
1A
1C
100m
(at 1A 24VDC)
AgCdO,AgSnO
2
NO:10A /250VAC
NC: 7A/ 250VAC
250VAC/30VDC
10A
2500VA 210W
1 x 10
7OPS
1 x 10
5OPS
COIL
Coil power
360mW
COIL DATA
Nominal
Voltage
VDC
3
5
6
9
12
Pick-up
Voltage
VDC
2.3
3.80
4.50
6.80
9.00
13.5
18.0
36.0
Drop-out
Voltage
VDC
0.3
0.5
0.6
0.9
1.2
1.8
2.4
4.8
Max.
Coil
allowable
Resistance
Voltage
VDC(at 25 )
3.9
6.5
7.8
11.7
15.6
23.4
31.2
62.4
25
70
100
225
400
900
1600
10%
10%
10%
10%
10%
10%
10%
General Purpose Power Relays JQC-7FD
CHARACTERISTICS
Initial Insulation Resistance
Dielectric Between coil and Contacts
Strength
Between open contacts
Operate time (at nomi. Volt.)
Release time (at nomi. Volt.)
Temperature rise (at nomi. Volt.)
Humidity
Shock Resistance
Functional
Destructive
Ambient temperature
Vibration Resistance
Termination
Unit weight
Construction
-40
100M
(500VDC)
2500VAC,1sec.
2000VAC, 1min.
750VAC, 1min.
Max. 10ms
Max. 5ms
60
35 to 85%RH
98 m/s
980 m/s
to +85
2
18
24
48
6200
(6400
available
)
10%
SAFETY APPROVAL RATINGS
1A
UL
1C
10A 277VAC @85
10A 28VDC @85
12A 125VAC @85
7A 250VAC @85
7A 28VDC @85
1A
VDE
1C
10A 250VAC @85
NC: 7A 250VAC @85
NO:10A 250VAC @85
2
1.5mm, 10 to 55Hz
PCB
Approx. 14g
Sealed IP67
& Unsealed
HONGFA RELAY
ISO9001*ISO/TS16949
*ISO14001
CERTIFIED
VERSION: EN02-20040601
