MICROCIRCUIT DATA SHEET

MJLM120-15-K REV 0BL

Original Creation Date: 07/06/95

Last Update Date: 09/26/96

Last Major Revision Date: 07/06/95

VOLTAGE REGULATOR -15 VOLTS AT 1.0A

Industry Part Number

LM120

NS Part Numbers

JL120-15BYA

JL120-15SYA

Prime Die

LM120

Controlling Document

38510/11507, AMEND.1

REV A

Processing

MIL-STD-883, Method 5004

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25

+125

-55

+25

+125

-55

+25

+125

-55

+25

+125

-55

Quality Conformance Inspection

MIL-STD-883, Method 5005

1
