INTERRUPTING RATING鈥?00,000A RMS SYM.
U.L. LISTED CLASS J (GUIDE # JDDZ, FILE # E4273)
*Contact Bussmann for DC ratings.
JKS-600 鈥?/div>
鈥?Single element, current limiting fuses provide superior short-cir-
cuit protection.
鈥?Protects low interrupting capacity circuit breakers. Limits the
short-circuit current to meet the interrupting capacity require-
ments of existing equipment.
鈥?On older systems available short circuit current may exceed the
interrupting capacity of the circuit breakers, fuses can be
installed in series with existing equipment.
鈥?Well suited for lighting and heating circuits and other non-induc-
tive loads.
鈥?Provides component short-circuit protection in compliance with
NEC 110-10, where protection devices shall clear a fault with-
out 鈥渆xtensive damage鈥?to the circuit components.
鈥?High interrupting rating helps meet the requirements of future
system expansion and the increases in available utility short-
circuit current.
鈥?Fuses can easily be selectively coordinated.
Carton Quantity and Weight鈥揓KS LIMITRON (600 Volts AC)*
Catalog
Number
70鈥?00
110鈥?00
225鈥?00
450鈥?00
Carton
Qty
5
1
1
1
Weight**
Lbs.
0.28
0.86
1.78
3.07
Kg.
0.127
0.390
0.807
1.392
Standard J Fuseblocks (600V) Catalog Data
Amps
70鈥?00
101鈥?00
201鈥?00
401鈥?00
Poles
3
1
1
1
Box Lug w/
Retaining Clip
J60100-3CR
J60200-1CR
J60400-1CR
J60600-1CR
Max. Wire
Size
1/0 Cu-Al
250MCM Cu-Al
500MCM Cu-Al
(2) 500MCM Cu-Al
**Weight per carton.
12-21-98
SB98107
Rev. A
Form No. JKS 70-600
Page 1 of 2
BIF Doc #1027
