Bussmann
廬
T-Tron
廬
Very Fast Acting Fuses
Class T
300 Volts, 1-1200 Amps
Dimensional Data
.88"
(鹵 0.02)
.41" Dia.
(鹵 0.02)
1A to 30A
.88"
(鹵 0.02)
.56" Dia.
(鹵 0.02)
35A to 60A
2.16"
(鹵 0.02)
.284"
(Typ. 2)
1.56"
.84"
.75"
(鹵 0.02)
70A to100A
2.44"
(鹵 0.02)
1.69"
.84"
.88"
(鹵 0.02)
110A to 200A
2.75"
(鹵 0.04)
1.84"
.86"
1"
(鹵 0.04)
225A to 400A
801A to 1200A
450A to 600A
3.38"
(鹵 0.04)
2.22"
.92"
3.06"
(鹵 0.04)
2.03"
.88"
JJN
1.25"
(鹵 0.04)
.484"
(Typ. 2)
1.75"
(鹵 0.04)
.562"
(Typ. 2)
Catalog Symbol:
JJN
Current Limiting
Very Fast Acting
Ampere Rating:
1 to1200 Amperes
Voltage Rating:
300 Volts AC (or less)*
Interrupting Rating:
200,000A RMS Sym.
Agency Approval:
UL Listed, Std. 248-15, Class T, Guide JDDZ, File E4273
CSA Certified, C22.2 No. 248.15, Class 1422-02, File 53787
Catalog Numbers
JJN-1
JJN-2
JJN-3
JJN-6
JJN-10
JJN-15
JJN-20
JJN-25
JJN-30
JJN-35
JJN-40
JJN-45
JJN-50
JJN-60
JJN-70
JJN-80
JJN-90
JJN-100
JJN-110
JJN-125
JJN-150
JJN-175
JJN-200
JJN-225
JJN-250
JJN-300
JJN-350
JJN-400
JJN-450
JJN-500
JJN-600
JJN-700
JJN-800
JJN-1000
JJN-1200
鈥?/div>
.344"
(Typ. 2)
601A to 800A
4"
(鹵 0.04)
2.53"
1.08"
.406"
(Typ. 2)
2"
(鹵 0.04)
.609"
(Typ. 2)
鈥?Small, space-saving fuses provide a high degree of current
limitation on short-circuits for excellent component protection.
鈥?Commonly applied in electric heat circuits, load center,
disconnect switches, and meters.
鈥?The small size of the T-Tron fuses permits installation in
panelboards and control centers for system upgrading when
existing circuit breakers cannot safely interrupt larger available
short-circuit currents.
鈥?High speed of response for semiconductor protection.
Standard T Fuseblocks (300V) Catalog Data
Catalog Numbers
Amps
鈦勨劍鈩?/div>
to
30
31
to
60
61
to
100
101 to
200
201 to 400
401 to 600
Poles
2
3
4
2
3
4
1
2
3
1
3
1
1
Screw
T30030-2SR
T30030-3SR
T30030-4SR
T30060-2SR
T30060-3SR
T30060-4SR
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Box Lug
T30030-2CR
T30030-3CR
T30030-4CR
T30060-2CR
T30060-3CR
T30060-4CR
T30100-1CR
T30100-2CR
T30100-3CR
T30200-1C
1B0083
T30400-1C
T30600-1C
Carton Quantity and Weight鈥揓JN-T-TRON (300 Volts AC)
Catalog
Number
1鈥?0
35鈥?0
70鈥?00
110鈥?00
225鈥?00
450鈥?00
700鈥?00
Carton
Qty.
10
10
5
1
1
1
1
Weight**
Lbs.
0.12
0.23
0.36
0.14
0.25
0.44
0.80
Kg.
0.054
0.104
0.163
0.063
0.113
0.200
0.363
1000鈥?200
1
1.45
0.658
*15-100A rated 300 VDC, 101-600A rated 160 VDC, 801-1200A rated 170 VDC
and 10 KAIC.
Weight per carton.
**
CE logo denotes compliance with European Union Low Voltage Directive
(50-1000 VAC, 75-1500 VDC). Refer to BIF document #8002 or contact
Bussmann Application Engineering at 636-527-1270 for more information.
Form No. JJN
Page 1 of 2
BIF Doc #1025
11-27-00
A00178
JJN-6 產品屬性
Cooper Bussmann
保險絲
6 Amps
300 Volts
Class T
Blade
Very Fast Acting
7/8 in L x 13/32 in W
Bulk
Industrial Power Fuse
200 KAmps
JJN-6
