JAN2N4033 Datasheet

  • JAN2N4033

  • TRANSISTOR | BJT | PNP | 80V V(BR)CEO | 1A I(C) | TO-39

  • 19頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

The documentation and process conversion
measures necessary to comply with this revision
shall be completed by 23 October 2001.
INCH-POUND
MIL-PRF-19500/512E
23 July 2001
SUPERSEDING
MIL-PRF-19500/512D
14 July 2000
PERFORMANCE SPECIFICATION
SEMICONDUCTOR DEVICE, TRANSISTOR, PNP, SILICON, SWITCHING
TYPES 2N4029, 2N4033, 2N4033UA, 2N4033UB, JAN, JANTX, JANTXV, JANS AND
JANKC2N4033 AND JANHC2N4033
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for PNP silicon transistors designed for use in
high speed switching and driver applications. Four levels of product assurance are provided for each encapsulated
device type and two levels of product assurance for each unencapsulated specified as in MIL-PRF-19500.
1.2 Physical dimensions. See figures 1 (TO-18), figure 2 (TO-39), figure 3 and figure 4 (surface mount) ) and
figure 5 (JANKC and JANHC) herein.
1.3 Maximum ratings.
P
T
(1)
T
A
= +25擄C
P
T
(2)
T
A
= +25擄C
P
T
(3)
T
A
= +25擄C
P
T
(1)
T
A
= +25擄C
V
CBO
V
CEO
V
EBO
I
C
T
OP
and T
STG
2N4029
W
0.5
2N4033
W
0.8
2N4033UA
W
0.65
2N4033UB
W
0.5
V dc
80
V dc
80
V dc
5.0
A dc
1.0
擄C
-65 to +200
R
胃
JA
2N4029
2N4033UB
擄C/W
325
R
胃
JA
2N4033
擄C/W
175
R
胃
JA
2N4033UA
擄C/W
210
(1) Derate linearly 3.08 mW/擄C above T
A
= +37.5擄C.
(2) Derate linearly 5.7 mW/擄C above T
A
= +60擄C.
(3) Derate linearly 4.76 mW/擄C above T
A
= +63.5擄C.
Beneficial comments (recommendations, additions, deletions) and any pertinent data which may be of use in
improving this document should be addressed to: Defense Supply Center, Columbus, ATTN: DSCC/VAC,
Post Office Box 3990, Columbus, OH 43216-5000, by using the Standardization Document Improvement Proposal
(DD Form 1426) appearing at the end of this document or by letter.
AMSC N/A
FSC 5961
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.

JAN2N4033 產品屬性

  • 0現貨查看交期

  • 100 : ￥103.62700散裝

  • Military, MIL-PRF-19500/512

  • 散裝

  • 在售

  • PNP

  • 1 A

  • 80 V

  • 1V @ 100mA，1A

  • 10μA（ICBO）

  • 100 @ 100mA，5V

  • 800 mW

  • -

  • -55°C ~ 200°C（TJ）

  • 通孔

  • TO-205AD，TO-39-3 金屬罐

  • TO-39（TO-205AD）
