JANTX2N3419 Datasheet

  • JANTX2N3419

  • TRANSISTOR | BJT | NPN | 80V V(BR)CEO | 3A I(C) | TO-5

  • 21頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

The documentation and process conversion
measures necessary to comply with this
revision shall be completed by 25 August 2001.
INCH-POUND
MIL-PRF-19500/393D
25 May 2001
SUPERSEDING
MIL-PRF-19500/393C
20 April 2000
PERFORMANCE SPECIFICATION
SEMICONDUCTOR DEVICE, TRANSISTOR, NPN, SILICON POWER
TYPES 2N3418, 2N3418S, 2N3419, 2N3419S, 2N3420, 2N3420S, 2N3421, 2N3421S
JAN, JANTX, JANTXV, JANS, JANHC, and JANKC
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1. Scope. This specification covers the performance requirements for NPN, silicon, transistors for use in
medium power switching applications. Four levels of product assurance are provided for each device type, and two
levels of product assurance for die (element evaluation) are provided, as specified in MIL-PRF-19500.
1.2. Physical dimensions. See figure 1 (similar to TO-5 for long leaded devices and TO-39 for short leaded
devices), figure 2, and figure 3 for JANHC and JANKC (die) dimensions.
1.3. Maximum ratings.
Type
P
T
T
A
= +25擄C
(1)
W
1.0
1.0
1.0
1.0
P
T
T
C
= +100擄C
(2)
W
15
15
15
15
V
CBO
V
CEO
V
EBO
I
C
I
C
(3)
A dc
5
5
5
5
T
STG
and T
OP
2N3418, 2N3418S
2N3419, 2N3419S
2N3420, 2N3420S
2N3421, 2N3421S
V dc
85
125
85
125
V dc
60
80
60
80
V dc
8
8
8
8
A dc
3
3
3
3
擄C
-65 to +200
-65 to +200
-65 to +200
-65 to +200
(1) Derate linearly at 5.72 mW/擄C above T
A
> +25擄C.
(2) Derate linearly at 150 mW/擄C above T
C
> +100擄C.
(3) This value applies for t
p
鈮?/div>
1 ms, duty cycle
鈮?/div>
50 percent.
Beneficial comments (recommendations, additions, deletions) and any pertinent data which may be of use in
improving this document should be addressed to: Defense Supply Center Columbus, ATTN: DSCC-VAC, Post
Office Box 3990, Columbus, OH 43216-5000, by using the Standardization Document Improvement Proposal (DD
Form 1426) appearing at the end of this document or by letter.
AMSC N/A
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
FSC 5961

JANTX2N3419 產品屬性

  • 0現貨查看交期

  • 100 : ￥176.36860散裝

  • Military, MIL-PRF-19500/393

  • 散裝

  • 在售

  • NPN

  • 3 A

  • 80 V

  • 500mV @ 200mA，2A

  • 5μA

  • 20 @ 1A，2V

  • 1 W

  • -

  • -65°C ~ 200°C（TJ）

  • 通孔

  • TO-205AA，TO-5-3 金屬罐

  • TO-5
