ISL6292
Data Sheet
July 25, 2005
FN9105.6
Li-ion/Li Polymer Battery Charger
The ISL6292 is an integrated single-cell Li-ion or Li- polymer
battery charger capable of operating with an input voltage as
low as 2.4V. This charger is designed to work with various
types of ac adapters or a USB port.
The ISL6292 operates as a linear charger when the ac
adapter is a voltage source. The battery is charged in a
CC/CV (constant current/constant voltage) profile. The
charge current is programmable with an external resistor up
to 2A. The ISL6292 can also work with a current-limited
adapter to minimize the thermal dissipation, in which case
the ISL6292 combines the benefits of both a linear charger
and a pulse charger.
The ISL6292 features charge current thermal foldback to
guarantee safe operation when the printed circuit board is
space limited for thermal dissipation. Additional features
include preconditioning of an over-discharged battery, an
NTC thermistor interface for charging the battery in a safe
temperature range, automatic recharge, and thermally
enhanced QFN or DFN packages.
Features
鈥?Complete Charger for Single-Cell Li-ion Batteries
鈥?Very Low Thermal Dissipation
鈥?Integrated Pass Element and Current Sensor
鈥?No External Blocking Diode Required
鈥?1% Voltage Accuracy
鈥?Programmable Current Limit up to 2A
鈥?Programmable End-of-Charge Current
鈥?Charge Current Thermal Foldback
鈥?NTC Thermistor Interface for Battery Temperature Monitor
鈥?Accepts Multiple Types of Adapters or USB BUS Power
鈥?Guaranteed to Operate at 2.65V After Start Up
鈥?Ambient Temperature Range: -20擄C to 70擄C
鈥?Thermally-Enhanced QFN Packages
鈥?Handheld Devices including Medical Handhelds
鈥?PDAs, Cell Phones and Smart Phones
鈥?Portable Instruments, MP3 Players
鈥?Self-Charging Battery Packs
鈥?Stand-Alone Chargers
PKG. DWG.
#
Ordering Information
PART # (NOTE)
ISL6292-1CR3
TEMP. RANGE (擄C)
-20 to 70
PACKAGE
鈥?USB Bus-Powered Chargers
鈥?Pb-Free Plus Anneal Available (RoHS Compliant)
10 Ld 3x3 DFN L10.3x3
ISL6292-1CR3-T 10 Ld 3x3 DFN Tape and Reel
ISL6292-2CR3
-20 to 70
10 Ld 3x3 DFN L10.3x3
Related Literature
鈥?Technical Brief TB363 鈥淕uidelines for Handling and
Processing Moisture Sensitive Surface Mount Devices
(SMDs)鈥?/div>
鈥?Technical Brief TB379 鈥淭hermal Characterization of
Packaged Semiconductor Devices鈥?/div>
鈥?Technical Brief TB389 鈥淧CB Land Pattern Design and
Surface Mount Guidelines for QFN Packages鈥?/div>
ISL6292-2CR3-T 10 Ld 3x3 DFN Tape and Reel
ISL6292-1CR4
-20 to 70
16 Ld 4x4 QFN L16.4x4
ISL6292-1CR4-T 16 Ld 4x4 QFN Tape and Reel
ISL6292-2CR4
-20 to 70
16 Ld 4x4 QFN L16.4x4
ISL6292-2CR4-T 16 Ld 4x4 QFN Tape and Reel
ISL6292-1CR5
-20 to 70
16 Ld 5x5 QFN L16.5x5B
Pinouts
ISL6292 (16 LEAD QFN)
TOP VIEW
VBAT
VBAT
VIN
VIN
ISL6292-1CR5-T 16 Ld 5x5 QFN Tape and Reel
ISL6292-2CR5
-20 to 70
16 Ld 5x5 QFN L16.5x5B
ISL6292 (10 LEAD DFN)
TOP VIEW
ISL6292-2CR5-T 16 Ld 5x5 QFN Tape and Reel
ISL6292EVAL1
ISL6292EVAL2
Evaluation Board for the 3x3 DFN Package Part.
Evaluation Board for the 4x4 QFN Package Part.
VIN 1
FAULT 2
STATUS 3
TIME 4
VIN
FAULT
12 VBAT
11 TEMP
10 IMIN
9 IREF
STATUS
TIME
GND
1
2
3
4
5
10 VBAT
9
8
7
6
TEMP
IREF
V2P8
EN
16 15 14 13
NOTE: Intersil Pb-free plus anneal products employ special Pb-free
material sets; molding compounds/die attach materials and 100% matte
tin plate termination finish, which are RoHS compliant and compatible
with both SnPb and Pb-free soldering operations. Intersil Pb-free
products are MSL classified at Pb-free peak reflow temperatures that
meet or exceed the Pb-free requirements of IPC/JEDEC J STD-020.
Add a 鈥淶鈥?to the end of the part # above for lead-free packages, e.g.,
鈥淚SL6292-1CR3Z-T鈥?is the part # for the lead-free ISL6292-1CR3-T.
5
GND
6
TOEN
7
EN
8
V2P8
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 1-888-468-3774
|
Intersil (and design) is a registered trademark of Intersil Americas Inc.
Copyright Intersil Americas Inc. 2003-2005. All Rights Reserved
All other trademarks mentioned are the property of their respective owners.
