ISL59441IA-T7 Datasheet

  • ISL59441IA-T7

  • 900MHz Multiplexing Amplifier

  • 12頁

  • INTERSIL   INTERSIL

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

廬
ISL59441
Data Sheet
September 21, 2005
FN6163.2
900MHz Multiplexing Amplifier
The ISL59441 is 900MHz bandwidth 4:1 multiplexing
amplifier designed primarily for video switching. This Mux
amp has a user-settable gain and also features a high speed
three-state function to enable the output of multiple devices
to be wired together. All logic inputs have pull-downs to
ground and may be left floating. The ENABLE pin, when
pulled high, sets the ISL59441 to the low current power-down
mode for power sensitive applications - consuming just 5mW.
TABLE 1. CHANNEL SELECT LOGIC TABLE
S1
0
0
1
1
X
X
S0
0
1
0
1
X
X
ENABLE
0
0
0
0
1
0
HIZ
0
0
0
0
X
1
OUTPUT
IN0
IN1
IN2
IN3
Power Down
High Z
Features
鈥?900MHz (-3dB) Bandwidth (A
V
= 1, V
OUT
= 100mV
P-P
)
鈥?230MHz (-3dB) Bandwidth (A
V
= 2, V
OUT
= 2V
P-P
)
鈥?Slew Rate (A
V
= 1, R
L
= 500
鈩?
V
OUT
= 4V) . . . . .1349V/碌s
鈥?Slew Rate (A
V
= 2, R
L
= 500
鈩?
V
OUT
= 5V) . . . . .1927V/碌s
鈥?Adjustable Gain
鈥?High Speed Three-State Output (HIZ)
鈥?Low Current Power-Down . . . . . . . . . . . . . . . . . . . . .5mW
鈥?Pb-Free Plus Anneal Available (RoHS Compliant)
Applications
鈥?HDTV/DTV Analog Inputs
鈥?Video Projectors
鈥?Computer Monitors
鈥?Set-top Boxes
鈥?Security Video
Pinout
NIC
IN0
NIC
IN1
GND
IN2
NIC
IN3
1
2
3
4
5
6
7
8
ISL59441 (16 LD QSOP)
TOP VIEW
16 ENABLE
15 HIZ
14
-
+
IN-
鈥?Broadcast Video Equipment
Ordering Information
PART
TAPE &
PART NUMBER MARKING REEL
ISL59441IA
ISL59441IA-T7
ISL59441IA-T13
ISL59441IAZ
(Note)
ISL59441IAZ-T7
(Note)
59441IA
59441IA
59441IA
59441IAZ
59441IAZ
-
7鈥?/div>
13鈥?/div>
-
7鈥?/div>
13鈥?/div>
PACKAGE
16 Ld QSOP
16 Ld QSOP
16 Ld QSOP
16 Ld QSOP
(Pb-free)
16 Ld QSOP
(Pb-free)
16 Ld QSOP
(Pb-free)
PKG.
DWG. #
MDP0040
MDP0040
MDP0040
MDP0040
MDP0040
MDP0040
13 OUT
12 V+
11
V-
10 S1
9
S0
Functional Diagram
EN0
S0
EN1
S1
DECODE
EN2
IN0
IN1
IN2
IN3
EN3
AMPLIFIER BIAS
HIZ
ENABLE
ENABLE pin must be low in order to activate the HIZ state
- OUT
+
IN-
ISL59441IAZ-T13 59441IAZ
(Note)
NOTE: Intersil Pb-free plus anneal products employ special Pb-free
material sets; molding compounds/die attach materials and 100%
matte tin plate termination finish, which are RoHS compliant and
compatible with both SnPb and Pb-free soldering operations. Intersil
Pb-free products are MSL classified at Pb-free peak reflow
temperatures that meet or exceed the Pb-free requirements of
IPC/JEDEC J STD-020.
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 1-888-468-3774
|
Intersil (and design) is a registered trademark of Intersil Americas Inc.
Copyright 漏 Intersil Americas Inc. 2005. All Rights Reserved.
All other trademarks mentioned are the property of their respective owners.

ISL59441IA-T7 產品屬性

  • 1,000

  • 集成電路 (IC)

  • 線性 - 放大器 - 視頻放大器和頻緩沖器

  • -

  • 4:1 多路復用器-放大器

  • -

  • 1

  • 900MHz

  • 1927 V/µs

  • 17mA

  • 180mA

  • -

  • 表面貼裝

  • 16-SSOP（0.154"，3.90mm 寬）

  • 16-QSOP

  • 帶卷 (TR)
