ISL23710WIU10Z Datasheet

  • ISL23710WIU10Z

  • Terminal Voltage +-3V or +-5V, 128 Taps Up/Down Interface

  • 232.68KB

  • 8頁

  • INTERSIL   INTERSIL

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

廬
ISL23710
Volatile Digitally Controlled Potentiometer (XDCP鈩?
Data Sheet
August 22, 2005
FN6126.0
Terminal Voltage 鹵3V or 鹵5V, 128 Taps
Up/Down Interface
The Intersil ISL23710 is a digitally controlled potentiometer
(XDCP). The device consists of a resistor array, wiper
switches, and a control section. The wiper position is
controlled by a Up/Down interface.
The potentiometer is implemented by a resistor array
composed of 127 resistive elements and a wiper switching
network. Between each element and at either end are tap
points accessible to the wiper terminal. The position of the
wiper element is controlled by the CS, U/D, and INC inputs.
The wiper register is volatile and is reset to midscale on
power up. The wiper position can be locked while powered
up to prevent inadvertent changes.
The device can be used as a three-terminal potentiometer or
as a two-terminal variable resistor in a wide variety of
applications including:
鈥?Industrial and Automotive Control
鈥?Parameter and Bias Adjustments
鈥?Amplifier Bias and Control
Features
鈥?Up/Down Interface with Chip Select Enable
鈥?DCP Terminal Voltage from 鹵2.7V to 鹵5V
鈥?127 Resistive Elements
- Typical R
TOTAL
tempco 鹵50ppm/擄C
- Ratiometric tempco 鹵4ppm/擄C
- End to end resistance range 鹵20%
- Wiper resistance = 70鈩?typ at V
CC
= 3.3V
鈥?Low Power CMOS
- V- = -2.7V to -5.5V
- V
CC
= 2.7V to 5.5V
- Active current, 1mA max
- Standby current, 500nA max
鈥?R
TOTAL
Values = 10k鈩? 50k鈩?/div>
鈥?Volatile Wiper Storage with Wiper Locking
鈥?Packages
- 10 Ld MSOP
鈥?Pb-Free Plus Anneal Available (RoHS Compliant)
Ordering Information
PART NUMBER
(BRAND)
ISL23710WIU10Z
(AOG) (Notes 1, 2)
ISL23710UIU10Z
(AOF) (Notes 1, 2)
NOTES:
1. Add 鈥?T鈥?suffix for tape and reel.
2. Intersil Pb-free plus anneal products employ special Pb-free material
sets; molding compounds/die attach materials and 100% matte tin
plate termination finish, which are RoHS compliant and compatible
with both SnPb and Pb-free soldering operations. Intersil Pb-free
products are MSL classified at Pb-free peak reflow temperatures that
meet or exceed the Pb-free requirements of IPC/JEDEC J STD-020.
RESISTANCE
OPTION (鈩?
10K
50K
TEMP
RANGE
(擄C)
PACKAGE
PKG.
DWG. #
Pinout
ISL23710
(10 LD MSOP)
TOP VIEW
-40 to +85 10 Ld MSOP M10.118
(Pb-Free)
-40 to +85 10 Ld MSOP M10.118
(Pb-Free)
U/D
V-
GND
CS
NC
1
2
3
4
5
10
9
8
7
6
INC
VCC
R
L
R
W
R
H
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 1-888-468-3774
|
Intersil (and design) is a registered trademark of Intersil Americas Inc.
XDCP is a trademark of Intersil, Inc. Copyright Intersil Americas Inc. 2005. All Rights Reserved
All other trademarks mentioned are the property of their respective owners.

ISL23710WIU10Z 產品屬性

  • Digitally Controlled Potentiometers

  • 980

  • 集成電路 (IC)

  • 數據采集 - 數字電位器

  • XDCP™

  • 128

  • 10k

  • 1

  • 標準值 ±50 ppm/°C

  • 易失

  • 3 線串行（芯片選擇，遞增，增/減）

  • 2.7 V ~ 5.5 V

  • -40°C ~ 85°C

  • 表面貼裝

  • 10-TFSOP，10-MSOP（0.118"，3.00mm 寬）

  • 10-MSOP

  • 管件
