IPS0551T(SMD220) Datasheet

  • IPS0551T(SMD220)

  • TRANSISTOR | MOSFET | N-CHANNEL | 37V V(BR)DSS | TO-273VAR

  • 107.73KB

  • 10頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Data Sheet No. PD60160-B
IPS0551T
FULLY PROTECTED POWER MOSFET SWITCH
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Over temperature shutdown
Over current shutdown
Active clamp
Low current & logic level input
E.S.D protection
Product Summary
R
ds(on)
V
clamp
I
shutdown
6.0m
鈩?/div>
(max)
40V
100A
4碌s
Description
The IPS0551T is a fully protected three terminal SMART
POWER MOSFET that features over-current, over-tem-
perature, ESD protection, and drain to source active
clamp. This device combines a HEXFET廬 POWER
MOSFET and a gate driver. It offers full protection and
high reliability required in harsh environments. The driver
allows short switching times and provides efficient protec-
tion by turning OFF the power MOSFET when temperature
exceeds 165
o
C or when the drain current reaches 100A.
The device restarts once the input is cycled. The ava-
lanche capability is significantly enhanced by the active
clamp and covers most inductive load demagnetiza-
tions.
T
on
/T
off
Package
SUPER SMD220
SUPER TO220
Typical Connection
L oad
D
IN
c o n tro l
R in s e r ie s
( if n e e d e d )
L o g ic s ig n a l
S
(Refer to lead assignment for correct pin configuration)
www.irf.com
1
