INA-51063-BLK Datasheet

  • INA-51063-BLK

  • 2.4 GHz Low Noise Silicon MMIC Amplifier

  • 69.37KB

  • 5頁

  • AGILENT   AGILENT

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

2.4 GHz Low Noise Silicon MMIC
Amplifier
Technical Data
INA-51063
Features
鈥?Ultra-Miniature Package
鈥?Internally Biased, Single 5 V
Supply (12 mA)
鈥?20.5 dB Gain
鈥?3 dB NF
鈥?Unconditionally Stable
Surface Mount SOT-363
(SC-70) Package
Description
Hewlett-Packard鈥檚 INA-51063 is a
Silicon monolithic amplifier that
offers excellent gain and noise
figure for applications to 2.4 GHz.
Packaged in an ultra-miniature
SOT-363 package, it requires half
the board space of a SOT-143
package.
The INA-51063 uses a topology
which is internally biased,
eliminating the need for external
components and providing
decreased sensitivity to ground
inductance.
The INA-51063 is fabricated using
HP鈥檚 30 GHz f
MAX
ISOSAT
TM
Silicon bipolar process which
uses nitride self-alignment sub-
micrometer lithography, trench
isolation, ion implantation, gold
metallization, and polyimide
intermetal dielectric and scratch
protection to achieve superior
performance, uniformity, and
reliability.
Applications
鈥?Amplifier for Cellular,
Cordless, Special Mobile
Radio, PCS, ISM, Wireless
LAN, DBS, TVRO, and TV
Tuner Applications
Pin Connections and
Package Marking
GND 1
6 OUTPUT
51
V
CC
RF
OUTPUT
GND 2
INPUT 3
5 GND
4 V
CC
Note:
Package marking provides
orientation and identification.
Equivalent Circuit (Simplified)
RF
INPUT
GROUND
6-151
5965-9680E
