ILN2003AN Datasheet

  • ILN2003AN

  • HIGH-VOLTAGE HIGH-CURRENT DARLINGTON TRANSISTOR ARRAYS

  • 8頁

  • INTEGRAL

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TECHNICAL DATA
HIGH-VOLTAGE HIGH-CURRENT
DARLINGTON TRANSISTOR ARRAYS
The ILN2003A are monolithic high-voltage, high-current
Darlington transistor arrays. Each consists of seven n-p-n
Darlington pairs that feature high-voltage outputs with common-
cathode clamp diodes for switching inductive loads. The collector-
current rating of a single Darlington pair is 500 mA. The
Darlington pairs may be paralleled for higher current capability.
Applications include relay drivers, hammer drivers, lamp drivers,
display drivers (LED and gas discharge), line drivers, and logic
buffers.
The ILN2003A has a 2.7-k
銆€
飥?/div>
series base resistor for each
Darlington pair for operation directly with TTL or 5-V CMOS
devices.
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
500-mA Rated Collector Current (Single Output)
High-Voltage Outputs . . . 50 V
Output Clamp Diodes
Inputs Compatible With Various Types of Logic
Relay Driver Applications
ILN2003A
ORDERING INFORMATION
ILN2003AN Plastic
ILN2003AD SOIC
T
A
= -20擄C to 85擄 C for all
packages
LOGIC SYSBOL
LOGIC DIAGRAM
SCHEMATICS (each Darlington Pair)
All resistor values shown are nominal.
ILN2003A: R
B
= 2.7 kW
1
