TECHNICAL DATA
Quad Single Supply Comparator
The IL339 consists of four independent precision voltage
comparators with an offset voltage specification as low as 2.0 mV max
for four comparators which were designed specifically to operate from
a single power supply over a wide range of voltages.
Application areas include limit comparators, simple analog to
digital converters; pulse, squarewave and time delay generators; wide
range VCO; MOS clock timers; multivibrators and high voltage digital
logic gates.
鈥?/div>
Single or Split Supply Operation
鈥?/div>
Low Input Bias Current
鈥?/div>
Low Input Offset Current
鈥?/div>
Input Common Mode Voltage Range to Gnd
鈥?/div>
Low Output Saturation Voltage
鈥?/div>
TTL and CMOS Compatible
IL339
ORDERING INFORMATION
IL339N Plastic
IL339D SOIC
T
A
= 0擄 to 70擄 C for all packages.
LOGIC DIAGRAM
PIN ASSIGNMENT
PIN 3 = V
CC
PIN 12 = GND
1
