Enhanced N channel FET with no inherent diode to Vcc
2.5鈩?bidirectional switches connect inputs to outputs
Zero propagation delay, zero ground bounce
Undershoot clamp diodes on all switch and control pins
Ultra low power with 0.2碌A(chǔ) typical Icc
Two enables control five bits each
Available in SOIC and QSOP Packages
IDTQS3LR384
DESCRIPTION:
The QS3LR384 provides a set of ten high-speed CMOS TTL-compatible
bus switches. Two banks of 5 switches are controlled by independent Bus
Enable (BE) signals. The very low R
ON
resistance (2.5鈩? of the QS3LR384
allows inputs to be connected without adding propagation delay and without
generating additional ground bounce noise.
The low ON resistance of the QS3LR384 makes it ideal for PCI hot-
plugging or hot-swapping applications.
The QS3LR384 is characterized for operation at -40擄C to +85擄C.
APPLICATIONS
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
Hot -swapping and hot-docking (low resistance for PCI and
Compact PCI applications)
Voltage translation (5V to 3.3V)
Power conservation
Capacitance reduction and isolation
Bus isolation
Clock gating
FUNCTIONAL BLOCK DIAGRAM
A
0
B
0
A
4
B
4
A
5
B
5
A
9
B
9
BEA
BEB
INDUSTRIAL TEMPERATURE RANGE
1
c
1999 Integrated Device Technology, Inc.
NOVEMBER 1999
DSC-5547/-
