IDTQS32XL384Q1 Datasheet

  • IDTQS32XL384Q1

  • QUICKSWITCH PRODUCTS HIGH-SPEED CMOS 20-BIT BUS SWITCH

  • 5頁

  • IDT

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

IDTQSIDTQS32XL384
HIGH-SPEED CMOS 20-BIT BUS SWITCH
INDUSTRIAL TEMPERATURE RANGE
QUICKSWITCH
廬
PRODUCTS
HIGH-SPEED CMOS
20-BIT BUS SWITCH
FEATURES:
DESCRIPTION:
IDTQS32XL384
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Enhanced N channel FET with no inherent diode to V
CC
5鈩?bidirectional switches connect inputs to outputs
鈩?/div>
Zero propagation delay, zero ground bounce
Undershoot Clamp Diodes on all switch and control Inputs
Four enables control five bits each
TTL-compatible input and output levels
Available in 48-pin QVSOP package
APPLICATIONS:
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
The QS32XL384 provides a set of twenty high-speed CMOS TTL-
compatible bus switches. The low ON resistance of the QS32XL384 allows
inputs to be connected to outputs without adding propagation delay and
without generating additional ground bounce noise. The Bus Enable (BE)
signals turn the switches on. Four Bus Enable signals are provided, one
for each of five bits of the 20-bit bus. The 鈥?84 family of QuickSwitch products
is ideal for switching wide digital buses, as well as hot-docking, 5V to 3V
conversion and capacitance isolation for power conservation.
The QS32XL384 is characterized for operation at -40擄C to +85擄C.
Hot-swapping, hot-docking
Voltage translation (5V to 3.3V)
Logic replacement (data processing)
Power conservation
Capacitance reduction and isolation
Low power for hand held and mobile applications
Bus isolation
Clock gating
FUNCTIONAL BLOCK DIAGRAM
A
0
B
0
A
10
B
10
A
4
A
5
B
4
B
5
A
14
A
15
B
14
B
15
A
9
B
9
A
19
B
19
BEA
BEC
BED
BEB
The IDT logo is a registered trademark of Integrated Device Technology, Inc.
INDUSTRIAL TEMPERATURE RANGE
1
c
2002 Integrated Device Technology, Inc.
APRIL 2002
DSC-5732/3
