Pin compatible with FCT16245
Flowthrough pinout for easy layout
Zero propagation delay, zero ground bounce
TTL-compatible input and output levels
Undershoot clamp diodes on all switch and control inputs
Available in SSOP package
DESCRIPTION:
The QS316245 provides a set of 16 high-speed CMOS TTL-compatible
bus switches (two banks of 8 switches each) in a flow-thru pinout. The low
ON resistance of the QS316245 allows inputs to be connected to outputs
without adding propagation delay and without generating additional ground
bounce noise. The Output Enable (OEx) signal turns the switches on similar
to the
OEx
signal of the 74鈥?45. The QS316245 is ideally suited for 5V to
3.3V translation, bus switching and isolation, and hot insertion.
QuickSwitch devices provide an order of magnitude faster speed than
conventional logic devices.
APPLICATIONS:
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Hot-swapping, hot-docking
Voltage translation (5V to 3.3V)
Bus switching, isolation
Power conservation, clock gating
Logic replacement
FUNCTIONAL BLOCK DIAGRAM
A
0
A
1
A
2
A
3
A
4
A
5
A
6
A
7
OE 1
B
0
B
1
B
2
B
3
B
4
B
5
B
6
B
7
A
8
A
9
A
10
A
11
A
12
A
13
A
14
A
15
OE 2
B
8
The IDT logo is a registered trademark of Integrated Device Technology, Inc.
B
9
B
10
B
11
B
12
B
13
B
14
B
15
INDUSTRIAL TEMPERATURE RANGE
1
c
2000 Integrated Device Technology, Inc.
JANUARY 2000
DSC-5720/1
