ICP-2020 Series
Voice Grade Channel
Processor
Features
q
Description
The ICP-2020 is M/A-COM鈥檚 newest Voice Grade Channel processor.
With an altogether new DSP board design, the ICP-2020 can be used
as a single channel processor or con鏗乬ured with an additional DSP
(ICP-2120) to process two voice grade channels simultaneously.
The ICP-2020 performs demodulation, demultiplexing, bit stream syn-
chronization and back-end processing for most commercially available
modem and voice frequency telegraphy (VFT) signals, as well as com-
plete Group 3 and V.17 FAX signals. In addition, the ICP-2020 can
generate the modem and VFT signals that it is designed to process.
Two analog inputs are available on the ICP-2020, and M/A-COM鈥檚
Dual Mode E1/T1 daughter card can be used to provide PCM Level 1
input to the ICP-2020.
The ICP-2020 comes standard with M/A-COM鈥檚 Control Monitor
Software for PC-based applications.
All of these new features represent the next generation in Voice Grade
Channel Processing from M/A-COM鈥檚 Communication Technologies
Center.
New Integrated Line Tracker Application
Provides Complete Dial-up and Standard
Modem Processing in One Package
Line Tracker Handles Dial-up Processing
of Bell 103, V.22bis, V.32bis and FAX
Signals
Complete Fax Processing, Including Group
3 and V.17
Modem Processor Handles OOK, FSK,
VFT, PSK and QAM for CCITT, Bell and
Motorola Equivalents
R.101A/B, 2400/1200 bps Strapping
Async, Bisync, HDLC, SDLC, X.25, SNA,
DDCMP, IPARS Protocols
ASCII-7, ASCII-8, EBCDIC, Baudot
Analog and PCM E1/T1 Inputs
PC Control Software (standard)
q
q
q
q
q
q
q
q
