Logarithmic Ampli鏗乪r
250 - 500 MHz
Features
q
q
q
ICLAP361/ICLA361
V3.00
C-22
Linearity 鹵1.0 dB Typical
Dynamic Range 70 dB Typical
Hermetically Sealed Microcircuit Construction
Guaranteed Speci鏗乧ations*
Dimensions in ( ) are in mm.
Unless Otherwise Noted: .xxx = 鹵0.010 (.xx = 鹵0.25)
.xx = 鹵0.02 (.x = 鹵0.5)
WEIGHT (APPROX.): 3.5 OUNCES 99 GRAMS
FP-12
Operating Characteristics
*All speci鏗乧ations apply when operated at 鹵12 VDC and with a 50 ohm
IF source and load impedance and 93 ohm load impedance.
Ordering Information
Part No.
ICLAP361 PIN
ICLA361 SMA
Package
Flatpack
Connectorized
Dimensions in ( ) are in mm.
Unless Otherwise Noted: .xxx = 鹵0.010 (.xx = 鹵0.25)
.xx = 鹵0.02 (.x = 鹵0.5)
WEIGHT (APPROX.): 0.81 OUNCES 23 GRAMS
Speci鏗乧ations Subject to Change Without Notice.
