ADE-208-038C(Z)
HVU315
Variable Capacitance Diode
for Wide Band tuner
Preliminary
Rev. 3
May. 1993
Features
鈥?High capacitance ratio. (n =10.3min)
鈥?Low series resistance. (r
s
=0.7鈩ax)
鈥?Ultra small Resin Package (URP) is suitable for
surface mount design.
1
Outline
Cathode mark
Mark
2
1. Cathode
2. Anode
Ordering Information
Type No.
HVU315
Laser Mark
K
Package Code
URP
Absolute Maximum Ratings
(Ta = 25擄C)
Item
Reverse voltage
Junction temperature
Storage temperature
Symbol
V
R
T
j
Tstg
Value
30
125
-55 to +125
Unit
V
擄C
擄C
Electrical Characteristics
(Ta = 25擄C)
Item
Reverse current
Capacitance
Capacitance ratio
Series resistance
Matching error
Symbol
I
R
C
2
C
25
n
r
s
鈭咰/C*
Min
鈥?/div>
27.6
2.67
10.3
鈥?/div>
鈥?/div>
Typ
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Max
10
32.1
3.02
鈥?/div>
0.70
2.0
Unit
nA
pF
鈥?/div>
鈩?/div>
%
Test Condition
V
R
= 30 V
V
R
= 2 V , f = 1 MHz
V
R
= 25 V , f = 1 MHz
C
2
/ C
25
V
R
= 5 V , f = 470 MHz
V
R
= 2~25 V
* A set of HVU315 is of uniform C-V characteristics.
Measure max. value and min. value of capacitance at each bias point of V
R
=2V through 25V.
Calculate Matching Error,
(Cmax-Cmin)
鈭咰/C=
x 100 (%)
Cmin
** Each group shall uniform a multiple of 4 diodes.
