ADE-208-188 (Z)
HSM125WK
Silicon Schottky Barrier Diode
for Battery Switch
Preliminary
Rev.0
Oct. 1993
Features
鈥?The HSM125WK has two different (V
F
- I
F
)
chips, and can change the main battery to the
backup battery automatically.
鈥?MPAK package is suitable for high density
surface mounting and high speed assembly.
Pin Arrangement
3
2
1
Ordering Information
Type No.
HSM125WK
Laser Mark
S13
Package Code
MPAK
(Top View)
1 Anode
2 Anode
3 Cathode
Absolute Maximum Ratings
(Ta = 25擄C)
Item
Peak reverse voltage
Forward current
Junction temperature
Storage temperature
* Per one device
Symbol
V
RM
I
F
*
T
j
Tstg
Value
Pin 1-3
20
500
125
-55 to +125
Value
Pin 2-3
20
100
125
-55 to +125
Unit
V
mA
擄C
擄C
Electrical Characteristics
(Ta = 25擄C)
Item
Forward voltage
Symbol
V
F1
V
F2
I
R
鈥?/div>
Pin 1-3
Pin 2-3
Pin 1-3
Pin 2-3
Pin 1-3
Pin 2-3
Min
0.1
0.5
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
200
Typ
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Max
0.3
0.8
0.55
1.2
30
0.1
鈥?/div>
V
碌A(chǔ)
V
Unit
V
Test Condition
I
F
= 1 mA
I
F
= 500 mA
I
F
= 100 mA
V
R
= 20 V
* C=200pF, Both forward
and reverse direction 1 pulse
Forward voltage
Reverse current
ESD Capability
* Failure Criterion ; Pin 1-3 (I
R
鈮?/div>
60碌A(chǔ) at V
R
= 20V) , Pin 2-3 (I
R
鈮?/div>
0.2碌A(chǔ) at V
R
= 20V)
