HZK Series

Silicon Epitaxial Planar Zener Diodes for

Stabilized Power Supply

REJ03G0018-0300Z

(Previous: ADE-208-126B)

Rev.3.00

May.14.2003

Features

鈥?/div>

Low leakage, low zener impedance and maximum power dissipation of 500 mW.

鈥?/div>

Wide spectrum from 1.9V through 38V of zener voltage provide flexible application.

鈥?/div>

LLD Package is suitable for high density surface mounting and high speed assembly.

Ordering Information

Type No.

HZK Series

Mark

Color Code

Package Code

LLD

Pin Arrangement

Cathode band

3rd. band

2nd. band

Cathode band

3rd. band

2nd. band

1. Cathode

2. Anode

Rev.3.00, May.14.2003, page 1 of 7
