HYS72V16201GR-8 Datasheet

  • HYS72V16201GR-8

  • x72 SDRAM Module

  • 220.22KB

  • 22頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

HYS 72Vx2xxGR
PC100 Registered SDRAM-Modules
3.3 V 168-pin Registered SDRAM Modules
64 MB, 128 MB, 256 MB, 512 MB & 1 GB Densities
鈥?168-pin JEDEC Standard, Registered 8 Byte
Dual-In-Line SDRAM Module
for PC and Server main memory applications
鈥?One bank 8M
脳
72, 16M
脳
72, 32M
脳
72 and
64M
脳
72 organization,
two bank 128M
脳
72 organization
鈥?Optimized for ECC applications with very low
input capacitances
鈥?Programmed Latencies:
Product Speed
-8
-8A
PC100
PC100
CL
2
3
t
RCD
t
RP
鈥?Programmable CAS Latency, Burst Length,
and Wrap Sequence (Sequential &
Interleave)
鈥?Auto Refresh (CBR) and Self Refresh
鈥?All inputs and outputs are LVTTL compatible
鈥?Serial Presence Detect with E
2
PROM
鈥?Utilizes SDRAMs in TSOPII-54 packages
with registers and PLL.
The two bank module uses stacked TSOP54
packages.
鈥?Card Size: 133.35 mm
脳
38.1 mm/
43.18 mm
脳
4,00/6.50 mm with Gold contact
pads
鈥?This specification follows INTEL鈥檚 鈥淧C
SDRAM Registered DIMM Specification鈥?/div>
Rev. 1.2
2
2
2
2
鈥?Single + 3.3 V (鹵 0.3 V) power supply
鈥?Performance:
-8
PC100
f
CK
t
CK
t
AC
-8A
PC100
100
10
6
Unit
Clock Frequency (max.)
Clock Cycle Time (min.)
Clock Access Time (min.)
100
10
6
MHz
ns
ns
The HYS 72Vx2x0GR family are industry standard 168-pin 8-byte Dual in-line Memory Modules
(DIMMs) which are organized as 8M
脳
72, 16M
脳
72, 32M
脳
72, 64M
脳
72 & 128M
脳
72 high speed
memory arrays designed with Synchronous DRAMs (SDRAMs) for ECC applications. The 32M x 72
(256MByte) registered DIMM module is available in two versions (12 or 13 row addresses). All
control and address signals are registered on-DIMM and the design incorporates a PLL circuit for
the Clock inputs. Use of an on-board register reduces capacitive loading on the input signals but are
delayed by one cycle in arriving at the SDRAM devices. Decoupling capacitors are mounted on the
PC board. The DIMMs use a serial presence detects scheme implemented via a serial E
2
PROM
using the 2-pin I
2
C protocol. The first 128 bytes are utilized by the DIMM manufacturer and the
second 128 bytes are available to the end user. All Infineon 168-pin DIMMs provide a high
performance, flexible 8-byte interface in a 133.35 mm long footprint.
Data Book
1
3.00
