HYS64V32300GU-7.5-C2 Datasheet

  • HYS64V32300GU-7.5-C2

  • x64 SDRAM Module

  • 279.27KB

  • 14頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

HYS 64/72V32300GU
SDRAM-Modules
3.3 V 32M
脳
64/72-Bit, 256MByte SDRAM Modules
168-pin Unbuffered DIMM Modules
鈥?168 Pin unbuffered 8 Byte Dual-In-Line
SDRAM Modules for PC main memory
applications using 256Mbit technology.
鈥?PC100-222, PC133-333 and PC133-222
versions
鈥?One bank 32M
脳
64 and 32M
脳
72
organisation
鈥?Optimized for byte-write non-parity or ECC
applications
鈥?Fully PC board layout compatible to INTEL鈥檚
Rev. 1.0 module specification
鈥?Programmed Latencies:
Product Speed
-7
-7.5
-8
PC133
PC133
PC100
CL
2
3
2
t
RCD
t
RP
鈥?Single + 3.3 V (
鹵
0.3 V) power supply
鈥?Programmable CAS Latency, Burst Length,
and Wrap Sequence (Sequential &
Interleave)
鈥?Auto Refresh (CBR) and Self Refresh
鈥?Decoupling capacitors mounted on substrate
鈥?All inputs, outputs are LVTTL compatible
鈥?Serial Presence Detect with E
2
PROM
鈥?Uses Infineon 256 Mbit SDRAM components
in 32M
脳
8 organization and TSOPII-54
packages
鈥?Gold contact pads, card size:
133.35 mm
脳
31.75 mm
脳
3.00 mm
(JEDEC MO-161-BA)
2
3
2
2
3
2
鈥?SDRAM Performance:
-7 / -7.5
PC133
f
CK
t
AC
-8
PC100
100
6
Unit
MHz
ns
Clock Frequency (max.)
Clock Access Time
133
5.4
Description
The HYS 64V32300GU and HYS 72V32300GU are industry standard 168-pin 8-byte Dual in-line
Memory Modules (DIMMs) which are organized as 32M
脳
64 and 32M
脳
72 in 1 memory bank high
speed memory arrays designed with 256M Synchronous DRAMs (SDRAMs) for non-parity and
ECC applications. The DIMMs use -7 speed sorted 32M
脳
8 SDRAM devices in TSOP54 packages
to meet the PC133-222 requirement, -7.5 components for PC133-333 and -8 components for the
standard PC100 applications. Decoupling capacitors are mounted on the PC board. The PC board
design is according to INTEL鈥檚 module specification. The DIMMs have a serial presence detect,
implemented with a serial E
2
PROM using the 2-pin I
2
C protocol. The first 128 bytes are utilized by
the DIMM manufacturer and the second 128 bytes are available to the end user. All Infineon 168-
pin DIMMs provide a high performance, flexible 8-byte interface in a 133.35 mm long footprint, with
1.25鈥?(31.75 mm) height.
INFINEON Technologies
1
9.01
