HYM76V4M655HGT6 Datasheet

  • HYM76V4M655HGT6

  • 8Mx64|3.3V|8/P/S|x4|SDR SDRAM - SO DIMM 64MB

  • 14頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

4M x64 bits
PC100 SDRAM SO DI
M
based on 4Mx16 SDRAM with LVTTL, 4 banks & 4K Refresh
HYM76V4M655HG(L)T6 Series
D E S C R IP T IO N
The Hynix HYM76V4M655HG(L)T6 Series are 4Mx64bits Synchronous DRAM Modules. The modules are composed of four
4Mx16bits CMOS Synchronous DRAMs in 400mil 54pin TSOP-II package, one 2Kbit EEPROM in 8pin TSSOP package on a 168pin
glass-epoxy printed circuit board. Two 0.33uF and one 0.1uF decoupling capacitors per each SDRAM are mounted on the PCB.
The Hynix HYM76V4M655HG(L)T6 Series are Dual In-line Memory Modules suitable for easy interchange and addition of 32Mbytes
memory. The Hyundai HYM76V4M655HG(L)T6 Series are fully synchronous operation referenced to the positive edge of the clock . All
inputs and outputs are synchronized with the rising edge of the clock input. The data paths are internally pipelined to achieve very high
bandwidth.
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
PC100MHz support
168pin SDRAM Unbuffered DIMM
Serial Presence Detect with EEPROM
1.00鈥?(25.40mm) Height PCB with double sided com-
ponents
Single 3.3鹵0.3V power supply
- 1, 2, 4 or 8 or Full page for Sequential Burst
鈥?/div>
鈥?/div>
All device pins are compatible with LVTTL interface
- 1, 2, 4 or 8 for Interleave Burst
Data mask function by DQM
鈥?/div>
Programmable CAS Latency ; 2, 3 Clocks
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
SDRAM internal banks : four banks
Module bank : one physical bank
Auto refresh and self refresh
4096 refresh cycles / 64ms
Programmable Burst Length and Burst Type
O R D E R IN G IN F O R M A T IO N
Part No.
HYM76V4M655HGT6-8
HYM76V4M655HGT6-P
HYM76V4M655HGT6-S
HYM76V4M655HGLT6-8
HYM76V4M655HGLT6-P
HYM76V4M655HGLT6-S
Clock
Frequency
125MHz
100MHz
100MHz
Internal
Bank
Ref.
Power
SDRAM
Package
Plating
Normal
4 Banks
4K
Low Power
TSOP-II
Gold
125MHz
100MHz
100MHz
This document is a general product description and is subject to change without notice. Hyundai Electronics does not assume any responsibility for use of
circuits described. No patent licenses are implied.
Rev. 0.3/Apr.01
