based on 16Mx16 SDRAM with LVTTL, 4 banks & 8K Refresh
HYM72V32M636H(L)T6 Series
DESCRIPTION
The HYM72V32M636H(L)T6 Series are 32Mx64bits Synchronous DRAM Modules. The modules are composed of eight 16Mx16bits
CMOS Synchronous DRAMs in 400mil 54pin TSOP-II package, one 2Kbit EEPROM in 8pin TSSOP package on a 144pin glass-epoxy
printed circuit board. One 0.22uF and one 0.0022uF decoupling capacitors per each SDRAM are mounted on the PCB.
The HYM72V32M636H(L)T6 Series are Dual In-line Memory Modules suitable for easy interchange and addition of 256Mbytes mem-
ory. The HYM72V32M636H(L)T6 Series are fully synchronous operation referenced to the positive edge of the clock . All inputs and
outputs are synchronized with the rising edge of the clock input. The data paths are internally pipelined to achieve very high bandwidth.
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
PC133/PC100MHz support
144pin SDRAM SO DIMM
Serial Presence Detect with EEPROM
1.25鈥?(31.75mm) Height PCB with single sided com-
ponents
Single 3.3鹵0.3V power supply
- 1, 2, 4 or 8 or Full page for Sequential Burst
鈥?/div>
鈥?/div>
All device pins are compatible with LVTTL interface
- 1, 2, 4 or 8 for Interleave Burst
Data mask function by DQM
鈥?/div>
Programmable CAS Latency ; 2, 3 Clocks
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
SDRAM internal banks : four banks
Module bank : two physical bank
Auto refresh and self refresh
8192 refresh cycles / 64ms
Programmable Burst Length and Burst Type
ORDERING INFORMATION
Part No.
HYM72V32M636HT6
-K
HYM72V32M636HT6
-H
HYM72V32M636HLT6
-K
HYM72V32M636HLT6
-H
Clock
Frequency
133MHz
133MHz
133MHz
133MHz
4 Banks
8K
Low Power
Internal
Bank
Ref.
Power
Normal
SDRAM
Package
Plating
TSOP-II
Gold
This document is a general product description and is subject to change without notice. Hynix Semiconductor Inc. does not assume any responsibility for
use of circuits described. No patent licenses are implied.
