HYM72V16M736BLFU6 Datasheet

  • HYM72V16M736BLFU6

  • 16Mx72|3.3V|H|x5|SDR SDRAM - SO DIMM 128MB

  • 13頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

16Mx72 bits
PC133 SDRAM SO DIMM
based on 16Mx16 SDRAM with LVTTL, 4 banks & 8K Refresh
HYM72V16M736BFU6 Series
DESCRIPTION
The HYM72V16M736BFU6 Series are 16Mx72bits Synchronous DRAM Modules. The modules are composed of five
16Mx16bits CMOS Synchronous DRAMs in 54ball FBGA package, one 2Kbit EEPROM in 8pin TSSOP package on a 144pin
glass-epoxy printed circuit board.
The HYM72V16M736BFU6 Series are Dual In-line Memory Modules suitable for easy interchange and addition of 128Mbytes
memory. The HYM72V16M736BFU6 Series are fully synchronous operation referenced to the positive edge of the clock . All
inputs and outputs are synchronized with the rising edge of the clock input. The data paths are internally pipelined to achieve
very high bandwidth.
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
PC133/PC100MHz support
144pin Micro SO DIMM
Serial Presence Detect with EEPROM
1.00鈥?(25.40mm) Height PCB with double sided compo-
nents
Single 3.3鹵0.3V power supply
- 1, 2, 4 or 8 or Full page for Sequential Burst
鈥?/div>
鈥?/div>
All device pins are compatible with LVTTL interface
- 1, 2, 4 or 8 for Interleave Burst
Data mask function by DQM
鈥?/div>
Programmable CAS Latency ; 2, 3 Clocks
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
SDRAM internal banks : four banks
Module bank : one physical bank
Auto refresh and self refresh
8192 refresh cycles / 64ms
Programmable Burst Length and Burst Type
ORDERING INFORMATION
Part No.
HYM72V16M736BFU6-H
Clock
Frequency
133MHz
Internal
Bank
4 Banks
Ref.
8K
Power
Normal
SDRAM
Package
54ball FBGA
Plating
Gold
This document is a general product description and is subject to change without notice. Hynix semiconductor does not assume any responsi-
bility for use of circuits described. No patent licenses are implied.
Rev. 0.1/May. 02
1
