32Mx72 bits
PC133 SDRAM Unbuffered DIMM
based on 16Mx8 SDRAM with LVTTL, 4 banks & 4K Refresh
HYM71V733201 H-Series
DESCRIPTION
The Hyundai HYM71V733201 H-Series are 32Mx72bits ECC Synchronous DRAM Modules. The modules are composed
of eighteen 16Mx8bit CMOS Synchronous DRAMs in 400mil 54pin TSOP-II package, one 2Kbit EEPROM in 8pin
TSSOP package on a 168pin glass-epoxy printed circuit board. One 0.22uF and one 0.0022uF decoupling capacitors per
each SDRAM are mounted on the PCB.
The HYM71V733201 H-Series are Dual In-line Memory Modules suitable for easy interchange and addition of
256Mbytes memory. The HYM71V733201 H-Series are offering fully synchronous operation referenced to a positive
edge of the clock. All inputs and outputs are synchronized with the rising edge of the clock input. The data paths are
internally pipelined to achieve very high bandwidth.
FEATURES
鈥?/div>
PC133/PC100MHz support
鈥?/div>
168pin SDRAM Unbuffered DIMM
鈥?/div>
Serial Presence Detect with EEPROM
鈥?/div>
1.375鈥?(34.93mm) Height PCB with Double Sided
components
鈥?/div>
Single 3.3
鹵
0.3V power supply
鈥?/div>
All devices pins are compatible with LVTTL interface
鈥?/div>
Data mask function by DQM
鈥?/div>
SDRAM internal banks : four banks
鈥?/div>
Module bank : two physical bank
鈥?/div>
Auto refresh and self refresh
鈥?/div>
4096 refresh cycles / 64ms
鈥?/div>
Programmable Burst Length and Burst Type
-. 1, 2, 4, 8 or Full Page for Sequential Burst
-. 1, 2, 4 or 8 for Interleave Burst
鈥?/div>
Programmable /CAS Latency
-. 2, 3 Clocks
ORDERING INFORMATION
PART NO.
HYM71V733201TH-75
HYM71V733201LTH-75
MAX.
FREQUENCY
133MHz
133MHz
INTERNAL
BANK
4 Banks
REF.
4K
POWER
Normal
Low Power
SDRAM
PACKAGE
TSOP-II
PLATING
Gold
This document is a general product description and is subject to change without notice. Hyundai Electronics does not assume
any responsibility for use of circuits described. No patent licenses are implied.
Rev. 1.1/Dec.99
漏1999
Hyundai MicroElectronics
