16Mx64 bits
PC100 SDRAM SO DIMM
based on 8Mx16 SDRAM with LVTTL, 4 banks & 4K Refresh
HYM71V65M1601 X-Series
DESCRIPTION
The Hyundai HYM71V65M1601 X-Series are 16Mx64bits Synchronous DRAM Modules. The modules are composed of
eight 8Mx16bit CMOS Synchronous DRAMs in 400mil 54pin TSOP-II package and 2Kbit EEPROM in 8pin TSSOP
package on a 144pin glass-epoxy printed circuit board. Two 0.33uF and one 0.1uF decoupling capacitors per each
SDRAM are mounted on the PCB.
The HYM71V65M1601 X-Series are Small Outline Dual In-line Memory Modules suitable for easy interchange and
addition of 128Mbytes memory. The HYM71V65M1601 X-Series are offering fully synchronous operation referenced to a
positive edge of the clock. All inputs and outputs are synchronized with the rising edge of the clock input. The data paths
are internally pipelined to achieve very high bandwidth.
FEATURES
鈥?/div>
PC100MHz support
鈥?/div>
144pin SDRAM SO DIMM
鈥?/div>
Serial Presence Detect with EEPROM
鈥?/div>
1.25鈥?(31.75mm) Height PCB with Double Sided
components
鈥?/div>
Single 3.3
鹵
0.3V power supply
鈥?/div>
All devices pins are compatible with LVTTL interface
鈥?/div>
Data mask function by DQM
鈥?/div>
SDRAM internal banks : four banks
鈥?/div>
Module bank : two physical bank
鈥?/div>
Auto refresh and self refresh
鈥?/div>
4096 refresh cycles / 64ms
鈥?/div>
Programmable Burst Length and Burst Type
-. 1, 2, 4, 8 or Full Page for Sequential Burst
-. 1, 2, 4 or 8 for Interleave Burst
鈥?/div>
Programmable /CAS Latency
-. 2, 3 Clocks
ORDERING INFORMATION
PART NO.
HYM71V65M1601TX-8
HYM71V65M1601TX-10P
HYM71V65M1601TX-10S
HYM71V65M1601LTX-8
HYM71V65M1601LTX-10P
HYM71V65M1601LTX-10S
MAX.
FREQUENCY
125MHz
100MHz
100MHz
4 Banks
125MHz
100MHz
100MHz
Low Power
4K
TSOP-II
Gold
Normal
INTERNAL
BANK
REF.
POWER
SDRAM
PACKAGE
PLATING
This document is a general product description and is subject to change without notice. Hyundai Electronics does not assume
any responsibility for use of circuits described. No patent licenses are implied.
Rev. 1.1/Dec.99
漏1999
Hyundai MicroElectronics
