HY51V64164,HY51V65164

4Mx16, Extended Data Out mode

1st Generation

DESCRIPTION

This family is a 64M bit dynamic RAM organized 4,194,304 x 16-bit configuration with Extended Data Out mode CMOS

DRAMs. Extended data out mode is a kind of page mode which is useful for the read operation. The circuit and process

design allow this device to achieve high performance and low power dissipation. Optional features are access time(60 or

70ns) and refresh cycle(8K ref. or 4K ref.) and power consumption (Normal or Low power with self refresh). Hyundai鈥檚

advanced circuit design and process technology allow this device to achieve high bandwidth, low power consumption and

high reliability.

FEATURES

鷗

Extended data out operation

鷗

Read-modify-write capability

鷗

Multi-bit parallel test capability

鷗

LVTTL(3.3V) compatible inputs and outputs

鷗

/CAS-before-/RAS, /RAS-only, Hidden and

Self refresh capability

鷗

Max. Active power dissipation

Speed

60

70

鷗

Refresh cycle

Part number

HY51V64164

1)

HY51V65164

2)

Refresh

8K

64ms

4K

128ms

Normal

L-part

8K refresh

504mW

432mW

4K refresh

648mW

576mW

鷗

JEDEC standard pinout

50-pin plastic TSOP-II (400mil)

鷗

Single power supply of 3.3

鹵

0.3V

鷗

Early write or output enable controlled write

鷗

Fast access time and cycle time

Speed

60

70

tRAC

60ns

70ns

tCAC

15ns

20ns

tHPC

25ns

30ns

1) Normal read / write, /RAS only refresh : 8K cycles / 64ms

/CAS-before-/RAS, Hidden refresh

: 4K cycles / 64ms

2) Normal read / write, /RAS only refresh : 4K cycles / 64ms

/CAS-before-/RAS, Hidden refresh

: 4K cycles / 64ms

ORDERING INFORMATION

Part Name

HY51V64164TC

HY51V64164LTC

HY51V64164SLTC

HY51V65164TC

HY51V65164LTC

HY51V65164SLTC

*SL : Self refresh with low power.

Refresh

8K

8K

8K

4K

4K

4K

Power

Package

50Pin TSOP-II

L-part

*SL-part

50Pin TSOP-II

50Pin TSOP-II

50Pin TSOP-II

L-part

*SL-part

50Pin TSOP-II

50Pin TSOP-II

This document is a general product description and is subject to change without notice. Hyundai electronics does not assume any responsibility for use of

circuits described. No patent licences are implied

Hyundai Semiconductor

Rev.00 / Oct.97

1

Powered by ICminer.com Electronic-Library Service CopyRight 2003
