HY5117804C,HY5116804C

2Mx8, Extended Data Out mode

DESCRIPTION

This family is a 16M bit dynamic RAM organized 2,097,152 x 8-bit configuration with Extended Data Out mode CMOS

DRAMs. Extended data out mode is a kind of page mode which is useful for the read operation. The circuit and process

design allow this device to achieve high performance and low power dissipation. Optional features are access time(60, 70

or 80ns) and refresh cycle(2K ref. or 4K ref.) and power consumption (Normal or Low power with self refresh). Hyundai鈥檚

advanced circuit design and process technology allow this device to achieve high bandwidth, low power consumption and

high reliability.

FEATURES

鷗

Extended data out operation

鷗

Read-modify-write Capability

鷗

TTL compatible inputs and outputs

鷗

/CAS-before-/RAS, /RAS-only, Hidden and

Self refresh capability

鷗

Max. Active power dissipation

Speed

60

70

80

鷗

Refresh cycle

Part number

HY5117804C

HY5116804C

Refresh

2K

4K

Normal

32ms

256ms

64ms

SL-part

2K refresh

660mW

550mW

495mW

4K refresh

550mW

495mW

440mW

鷗

JEDEC standard pinout

鷗

28-pin Plastic SOJ (300mil)

28-pin plastic TSOP-II (300mil)

鷗

Single power supply of 5V

鹵

10%

鷗

Early write or output enable controlled write

鷗

Fast access time and cycle time

Speed

60

70

80

tRAC

60ns

70ns

80ns

tCAC

15ns

20ns

20ns

tHPC

25ns

30ns

35ns

ORDERING INFORMATION

Part Name

HY5117804CJ

HY5117804CSLJ

HY5117804CT

HY5117804CSLT

HY5116804CJ

HY5116804CSLJ

HY5116804CT

HY5116804CSLT

*SL : Low power with self refresh

This document is a general product description and is subject to change without notice. Hyundai electronics does not assume any responsibility for use of

circuits described. No patent licences are implied

Hyundai Semiconductor

Rev.00 / Sep.97

Refresh

2K

2K

2K

2K

4K

4K

4K

4K

Power

Package

28Pin SOJ

SL-part

28Pin SOJ

28Pin TSOP-II

SL-part

28Pin TSOP-II

28Pin SOJ

SL-part

28Pin SOJ

28Pin TSOP-II

SL-part

28Pin TSOP-II

1

Powered by ICminer.com Electronic-Library Service CopyRight 2003
