HT93LC66-B Datasheet

  • HT93LC66-B

  • Microwire Serial EEPROM

  • 10頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

4K 3-Wire CMOS Serial EEPROM
Features
路
路
路
路
路
HT93LC66
Operating voltage V
CC
鈥?/div>
Read: 2.0V~5.5V
鈥?/div>
Write: 2.4V~5.5V
Low power consumption
鈥?/div>
Operating: 5mA max.
鈥?/div>
Standby: 10mA max.
User selectable internal organization
鈥?/div>
4K(HT93LC66): 512麓8 or 256麓16
3-wire Serial Interface
Write cycle time: 5ms max.
路
路
路
路
路
路
路
路
Automatic erase-before-write operation
Word/chip erase and write operation
Write operation with built-in timer
Software controlled write protection
10-year data retention after 100K rewrite
cycles
6
10 rewrite cycles per word
Commercial temperature range
(0擄C to +70擄C)
8-pin DIP/SOP package
General Description
The HT93LC66 is a 4K-bit low voltage nonvola-
tile, serial electrically erasable programmable
read only memory device using the CMOS float-
ing gate process. Its 4096 bits of memory are or-
ganized into 256 words of 16 bits each when the
ORG pin is connected to VCC or organized into
512 words of 8 bits each when it is tied to VSS.
The device is optimized for use in many indus-
trial and commercial applications where low
power and low voltage operation are essential. By
popular microcontroller, the versatile serial in-
terface including chip select (CS), serial clock
(SK), data input (DI) and data output (DO) can be
easily controlled.
Block Diagram
C S
S K
O R G
C o n tro l
L o g ic
a n d
C lo c k
G e n e ra to r
A d d re s s
R e g is te r
V C C
A d d re s s
D e c o d e r
V S S
D I
D a ta
R e g is te r
M e m o r y C e ll
A rra y
4 K : (5 1 2
麓
8 o r 2 5 6
麓
1 6 )
O u tp u t
B u ffe r
D O
1
December 7, 2000
