Surface Mount Microwave
Schottky Mixer Diodes
Technical Data
HSMS-8101 Single
HSMS-8202 Series Pair
HSMS-8207 Ring Quad
HSMS-8209 Crossover Quad
Features
鈥?Optimized for use at
10-14 GHz
鈥?Low Capacitance
鈥?Low Conversion Loss
鈥?Low RD
鈥?Low Cost Surface Mount
Plastic Package
Plastic SOT-23 Package
Package Lead Code
Identification
(Top View)
SINGLE
3
SERIES
3
1
#1
2
1
#2
2
Plastic SOT-143 Package
Description/Applications
These low cost microwave
Schottky diodes are specifically
designed for use at X/Ku-bands
and are ideal for DBS and VSAT
downconverter applications. They
are available in SOT-23 and
SOT-143 standard package
configurations.
Note that Agilent's manufacturing
techniques assure that dice found
in pairs and quads are taken from
adjacent sites on the wafer,
assuring the highest degree of
match.
RING
QUAD
3
4
CROSS-OVER
QUAD
3
4
1
#7
2
1
#9
2
Absolute Maximum Ratings
[1]
, T
A
= +25擄C
Symbol Parameter
P
T
P
IV
T
J
T
STG
, T
op
Total Device Dissipation
[2]
Peak Inverse Voltage
Junction Temperature
Storage and Operating
Temperature
Unit
mW
V
擄C
擄C
Min.
鈥?/div>
鈥?/div>
鈥?/div>
-65
Max.
75
4
+150
+150
Notes:
1. Operation in excess of any one
of these conditions may result
in permanent damage to the
device.
2. Measured in an infinite heat
sink at T
CASE
= 25擄C. Derate
linearly to zero at 150擄C per
diode.
ESD WARNING:
Handling Precautions Should Be Taken To Avoid Static Discharge.
