Infrared IrDA

廬

Compliant

Transceiver

Technical Data

HSDL-1000

Features

鈥?Low Cost Infrared Data Link

鈥?Guaranteed to Meet IrDA

Physical Layer Specifications

1 cm to 1 Meter Operating

Distance

30擄 Viewing Angle

2.4 KBd to 115.2 KBd Data

Rate

鈥?Daylight Cancellation

鈥?Easily Implemented Direct

Connection to Various I/O

Chips

鈥?Small Form Factor

鈥?Several Lead and Shipping

Configurations Available

鈥?Excellent EMI Immunity

(> 10 V/m)

Desktop PCs

PDAs

Printers

Other Peripheral Devices

鈥?Telecom:

Modem, Fax, Pager, Phone

鈥?Industrial:

Data Collection Devices

鈥?Medical:

Patient and Pharmaceutical

Data Collection

operate from 0 to 1 meter at a

data rate of 115.2 Kbd at a 30擄

viewing angle.

The HSDL-1000 contains a high

speed, high efficiency TS AlGaAs

875 nm LED, a PIN Silicon photo-

diode and an integrated circuit.

The IC contains an LED driver,

amplifiers and a quantizer.

The module is designed to inter-

face directly with selected I/O

chips that incorporate logic which

performs pulse width modulation/

demodulation.

V+

LED

Description:

The HSDL-1000 serial infrared

module performs low cost, low

power, point-to-point, through the

air data transfer in a serial, half-

duplex mode.

The module has been designed to

the IrDA (Infrared Data Associa-

tion) Physical Layer Specifica-

tions. The module is designed to

Applications

鈥?Data Comm: Serial Data

Transfer Between:

Notebook Computers

Subnotebooks

Schematic

BUTTRESS

LEAD*

TXD

LED C

LED

LED A

PIN ONE

RXD

PHOTODIODE

COMPARATOR

RXD

CX1

1000

YYWW

V+

CX2

PIN ONE

INDICATOR

PIN ONE

CX4 CX3

CX2

GND

* SIDE BUTTRESS LEADS ARE FOR MECHANICAL STABILITY AND

SHOULD NOT BE CONNECTED TO ANY ELECTRICAL POTENTIAL.
