HD74LVC534 Datasheet

  • HD74LVC534

  • Octal D-type Flip Flops with 3-state Outputs

  • 201.33KB

  • 8頁

  • RENESAS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

HD74LVC534
Octal D-type Flip Flops with 3-state Outputs
REJ03D0357鈥?400Z
(Previous ADE-205-071B (Z))
Rev.4.00
Jul. 27, 2004
Description
The HD74LVC534 has eight edge trigger D type flip flops with three state outputs in a 20 pin package. Data at the D
inputs meeting set up requirements are transferred to the Q outputs on positive going transitions of the clock input.
When the latch enable goes low, data at the D inputs will be retained at the outputs until latch enable returns high again.
When a high logic level is applied to the output control input, all outputs go to a high impedance state, regardless of
what signals are present at the other inputs and the state of the storage elements. Low voltage and high-speed operation
is suitable at the battery drive product (note type personal computer) and low power consumption extends the life of a
battery for long time operation.
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
V
CC
= 2.0 V to 5.5 V
All inputs V
IH
(Max.) = 5.5 V (@V
CC
= 0 V to 5.5 V)
Typical V
OL
ground bounce < 0.8 V (@V
CC
= 3.3 V, Ta = 25擄C)
Typical V
OH
undershoot > 2.0 V (@V
CC
= 3.3 V, Ta = 25擄C)
High output current 鹵24 mA (@V
CC
= 3.0 V to 5.5 V)
Ordering Information
Package Type
SOP鈥?0 pin (JEITA)
TSSOP鈥?0 pin
Package Code
FP鈥?0DAV
TTP鈥?0DAV
Package
Abbreviation
FP
T
Taping Abbreviation
(Quantity)
EL (2,000 pcs/reel)
ELL (2,000 pcs/reel)
Part Name
HD74LVC534FPEL
HD74LVC534TELL
Note: Please consult the sales office for the above package availability.
Function Table
Inputs
G
H
L
L
L
H:
L:
X:
Z:
鈫?/div>
:
Q
0
:
CK
X
鈫?/div>
鈫?/div>
L
D
X
L
H
X
Output
Q
Z
H
L
Q
0
High level
Low level
Immaterial
High impedance
Low to high transition
Level of
Q
before the indicated steady input conditions were established.
Rev.4.00 Jul. 27, 2004 page 1 of 7
