HD74LV540A
Octal Inverted Buffers / Drivers with 3-state Outputs
REJ03D0334鈥?200Z
(Previous ADE-205-277 (Z))
Rev.2.00
Jun. 28, 2004
Description
The HD74LV540A has eight inverter drivers with three state outputs in a 20 pin package. When
OE1
and
OE2
is low
level, this drivers set up output is enable. Low-voltage operation is suitable for battery-powered products (e.g.,
notebook computers), and the low-power consumption extends the battery life.
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
V
CC
= 2.0 V to 5.5 V operation
All inputs V
IH
(Max.) = 5.5 V (@V
CC
= 0 V to 5.5 V)
All outputs V
O
(Max.) = 5.5 V (@V
CC
= 0 V)
Typical V
OL
ground bounce < 0.8 V (@V
CC
= 3.3 V, Ta = 25擄C)
Typical V
OH
undershoot > 2.3 V (@V
CC
= 3.3 V, Ta = 25擄C)
Output current 鹵8 mA (@V
CC
= 3.0 V to 3.6 V), 鹵16 mA (@V
CC
= 4.5 V to 5.5 V)
Ordering Information
Package Type
SOP鈥?0 pin (JEITA)
SOP鈥?0 pin (JEDEC)
TSSOP鈥?0 pin
Package Code
FP鈥?0DAV
FP鈥?0DBV
TTP鈥?0DAV
Package
Abbreviation
FP
RP
T
Taping Abbreviation
(Quantity)
EL (2,000 pcs/reel)
EL (1,000 pcs/reel)
ELL (2,000 pcs/reel)
Part Name
HD74LV540AFPEL
HD74LV540ARPEL
HD74LV540ATELL
Note: Please consult the sales office for the above package availability.
Function Table
Inputs
OE1
L
L
H
X
Note: H:
L:
X:
Z:
High level
Low level
Immaterial
High impedance
OE2
L
L
X
H
A
L
H
X
X
Output
Y
H
L
Z
Z
Rev.2.00 Jun. 28.2004 page 1 of 9
