HD74LV221A Datasheet

  • HD74LV221A

  • Dual Monostable Multivibrators

  • 19頁

  • HITACHI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

HD74LV221A
Dual Monostable Multivibrators
ADE-205-271A (Z)
2nd Edition
June 1999
Description
The HD74LV221A features output pulse-duration control by three methods. In the first method, the A
input is low and the B input goes high. In the second method, the B input is high and the
A
input goes low.
In the third method, the
A
input is low, the B input is high, and the clear (CLR) input goes high.
The basic pulse duration is programmed by selecting external resistance and capacitance values. The
external timing capacitor must be connected between Cext and Rext/Cext (positive) and an external resistor
connected between Rext/Cext and V
CC
.
To obtain variable pulse durations, connect an external variable resistance between Rext/Cext and VCC.
Pulse duration can be reduced by taking
CLR
low.
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
V
CC
= 2.0 V to 5.5 V operation
All inputs V
IH
(Max.) = 5.5 V (@V
CC
= 0 V to 5.5 V)
All outputs V
O
(Max.) = 5.5 V (@V
CC
= 0 V)
Output current
鹵6
mA (@V
CC
= 3.0 V to 3.6 V),
鹵12
mA (@V
CC
= 4.5 V to 5.5 V)
