HD74LV1GW16A_06 Datasheet

  • HD74LV1GW16A_06

  • Dual Buffer

  • 85.61KB

  • 6頁

  • RENESAS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

HD74LV1GW16A
Dual Buffer
REJ03D0078-0200
Rev.2.00
May 19, 2006
Description
The HD74LV1GW16A has dual buffer in a 6 pin package. Low voltage and high-speed operation is suitable for the
battery powered products (e.g., notebook computers), and the low power consumption extends the battery life.
Features
鈥?/div>
The basic gate function is lined up as Renesas uni logic series.
鈥?/div>
Supplied on emboss taping for high-speed automatic mounting.
鈥?/div>
Supply voltage range : 1.65 to 5.5 V
Operating temperature range : 鈥?0 to +85擄C
鈥?/div>
All inputs V
IH
(Max.) = 5.5 V (@V
CC
= 0 V to 5.5 V)
All outputs V
O
(Max.) = 5.5 V (@V
CC
= 0 V)
鈥?/div>
Output current 鹵6 mA (@V
CC
= 3.0 V to 3.6 V), 鹵12 mA (@V
CC
= 4.5 V to 5.5 V)
鈥?/div>
All the logical input has hysteresis voltage for the slow transition.
鈥?/div>
Ordering Information
Part Name
HD74LV1GW16ACME
Package Type
CMPAK-6 pin
Package Code
(Previous Code)
PTSP0006JA-A
(CMPAK-6V)
Package
Abbreviation
CM
Taping Abbreviation
(Quantity)
E (3,000 pcs / Reel)
Outline and Article Indication
鈥?HD74LV1GW16A
Index band
Marking
W J
CMPAK鈥?
= Control code
Function Table
Input A
H
L
H : High level
L : Low level
Output Y
H
L
Rev.2.00, May 19, 2006 page 1 of 5
