HD74HC589

8-bit Serial of Parallel-input/Serial-output Shift Register

(with 3-state outputs)

Description

The HD74HC589 is similar in function to the HD74HC597, which is not a 3-state device.

This device consists of an 8-bit storage latch which feeds parallel data to an 8-bit shift register. Data can

also be loaded serially (see Function Table). The shift register output, O

, is a three-state output, allowing

this device to be used in bus-oriented systems.

Features

鈥?/div>

High Speed Operation: t

(Shift Clock to Q

) = 15 ns typ (C

= 50 pF)

High Output Current: Fanout of 15 LSTTL Loads

Wide Operating Voltage: V

= 2 to 6 V

Low Input Current: 1 碌A(chǔ) max

Low Quiescent Supply Current: I

(static) = 4 碌A(chǔ) max (Ta = 25擄C)

Function Table

Latch Clock

LCK

Shift Clock

SCK

L, H,

Serial Shift/

Parallel Load

Output Enable

Function

Data are loaded into input latches

Data are loaded from input into shift

registers

Data are transfered from input

latches to shift registers

Outputs are disabled

Serial shift Q

= Q

n 鈥?1

, Q

= SER
