HD74ALVC2G245
Dual Bus Transceivers with 3-state Output
ADE-205-641B (Z)
Rev.2
Apr. 2002
Description
The HD74ALVC2G245 has two buffers with three state output in a 8 pin package. When DIR is high, data
is transferred from the A inputs to the B outputs, and when DIR is low, data is transferred from the B inputs
to the A outputs. The A and B buses are separated by making the enable input (OE) high level. Low
voltage and high speed operation is suitable for the battery powered products (e.g., notebook computers),
and the low power consumption extends the battery life.
Features
鈥?/div>
The basic gate function is lined up as hitachi uni logic series.
鈥?/div>
Supplied on emboss taping for high speed automatic mounting.
鈥?/div>
Supply voltage range : 1.2 to 3.6 V
Operating temperature range :
鈭?0
to +85擄C
鈥?/div>
All inputs V
IH
(Max.) = 3.6 V (@V
CC
= 0 V to 3.6 V)
All outputs V
O
(Max.) = 3.6 V (@V
CC
= 0 V)
鈥?/div>
Output current
鹵2
mA (@V
CC
= 1.2 V)
鹵4
mA (@V
CC
= 1.4 V to 1.6 V)
鹵6
mA (@V
CC
= 1.65 V to 1.95 V)
鹵18
mA (@V
CC
= 2.3 V to 2.7 V)
鹵24
mA (@V
CC
= 3.0 V to 3.6 V)
鈥?/div>
Package type
Package type
SSOP-8 pin
Package code
TTP-8DB
Package suffix
US
Taping code
E (3,000 pcs / Reel)
