Series HA60/HD60
25-125Amp 鈥?600 Vac 鈥?AC Output
鈥?Zero Voltage and Random
Turn-On Switching
鈥?Panel Mount
鈥?1200V Blocking Capability
鈥?600Vac - the preferred
choice in Canada
Featuring state-of-the-art Surface
Mount Technology, these SPST-NO
relays deliver proven reliability in the
most demanding applications.
Output consists of an SCR AC switch
and is available in zero-cross, random
turn-on (phase controllable) and ver-
sions with either AC or DC input (coil)
control.
Manufactured in Crydom鈥檚 ISO 9002
Certified facility for optimum product
performance and reliability.
HA6090
HD6090
600
48-660
90
40
1200
1,200
1.7
0.28
6,000
5
500
HA60125
HD60125
600
48-660
125
150
1200
1,750
1.7
0.22
12,700
5
500
MODEL NUMBERS
AC CONTROL
D C C ONTROL
HA6025
HD6025
600
48-660
25
40
1200
250
1.7
1.02
260
5
500
HA6050
HD6050
600
48-660
50
40
1200
625
1.7
0.63
1,620
5
500
OUTPUT SPECIFICATIONS
聦
Nominal Line Voltage (
鹵
10%) [Vrms]
Operating Voltage Range (47-63 Hz) [Vrms]
Max. Load Current
聨
[Arms]
Min. Load Current, [mArms]
Transient Overvoltage [Vpk]
Max. Surge Current, (16.6ms) [Apk]
Max. On-State Voltage Drop @ Rated Current [Vpk]
Thermal Resistance Junction to Case (R
胃JC
) [藲C/W]
Maximum I2 t for Fusing, (8.3 msec.) [A2sec]
Max. Off-State Leakage Current @ Rated Voltage [mArms]
聮
Min. Off-State dv/dt @ Max. Rated Voltage [V/碌sec]
聧
Max. Turn-On Time
聬
Max. Turn-Off Time
Power Factor (Min.) with Max. Load
1/2 Cycle (DC Input), 10.0 msec (AC Input)
1/2 Cycle (DC Input), 40.0 msec (AC Input)
0.5
0.5
0.5
0.5
INPUT SPECIFICATIONS
聦
Control Voltage Range
Max. Reverse Voltage
Max. Turn-On Voltage
Min. Turn-Off Voltage
Nominal Input Impedance
Typical Input Current
DC CONTROL
(D PREFIX)
AC CONTROL
(A PREFIX)
聫
90-280 Vrms (60Hz)
---
90 Vrms
10 Vrms
60K Ohms
2mA @ 120 Vrms, 4mA @ 240 Vrms
AC CONTROL
(E SUFFIX)
3-32 Vdc
-32 Vdc
3.0 Vdc
1.0 Vdc
See Note
聭
2.0 mA
聭
18-36 Vrms
---
18 Vrms
4.0 Vrms
9.0K Ohms
3mA @ 24 Vrms
GENERAL NOTES
漏1998 CRYDOM CORP, Specifications subject to change without
notice.
聦
All parameters at 25潞C unless otherwise specified.
聧
Off-State dv/dt test method per EIA/NARM standard RS-443, paragraph 13.11.1
聨
Heat sinking required, for derating curves see page 2.
聫
24 Vac Input option, E suffix.
聬
Turn-on time for random turn-on versions is 0.02 msec (DC Control Models).
聭
Input circuitry incorporates active current limiter.
For recommended applications and more information contact:
聮
No internal snubber.
USA:
(800) 8 CRYDOM
鈥?/div>
(800) 827-9366 鈥?(619) 715-7200 鈥?fax (619) 715-7280
Crydom Corp, 9525 Chesapeake Drive, San Diego, CA 92123 鈥?e-mail: sales@crydom.com
WEB SITE:
http://www.crydom.com
FASTFAX Product Information:
(888) 267-9191
UK:
(44)1202 812300
鈥?/div>
fax (44)1202 812340 Crydom International Ltd., 85, Condor Close,
Woolsbridge Industrial Estate, Three-Legged Cross. Wimborne, Dorset, England BH21 6SU
GERMANY:
(49) (0)6874 182580
鈥?/div>
fax (49)(0)6874 182585 Crydom GmbH,
Gewerbegebiet Im Schachen, D-66687 Nunkirchen, Germany 鈥?e-mail: vertrieb@crydom.com
FastFax Document No.159
SERIES HA/HD60.032698, PAGE 1 OF 3
