HD404054 Series/HD404094 Series
Rev. 6.0
Sept. 1998
Description
The HD404054 Series and HD404094 Series are HMCS400-series microcomputers designed to increase
program productivity with large-capacity memory. Each microcomputer has three timers, one serial
interface, comparator, input capture circuit.
The HD404054 Series includes three chips: the HD404052 with 2-kword ROM; the HD404054 with 4-
kword ROM; and the HD4074054 with 4-kword PROM (ZTAT鈩?version). Also, the HD404094 Series
includes three chips: the HD404092 with 2-kword ROM; the HD404094 with 4-kword ROM; and the
HD4074094 with 4-kword PROM (ZTAT鈩?version).
The HD4074054 and HD4074094 are PROM version (ZTAT鈩?microcomputers). Program can be written
to the PROM by a PROM writer, which can dramatically shorten system development periods and smooth
the process from debugging to mass production. (The ZTAT鈩ersion is 27256-compatible.)
Features
鈥?/div>
The differences between HD404054 Series and HD404094 Series
HD404054 Series
I/O pins
10 large-current output pins: Six 15-mA sinks
and four 10-mA sources
HD404094 Series
鈥?/div>
鈥?/div>
6 largecurrent output pins: Two 15-mA
sinks and four 10-mA sources
4 intermediate voltage output pins
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
27 I/O pins and 8 dedicated input pins
Three timer/counters
Eight-bit input capture circuit
Two timer outputs (including two PWM outputs)
One event counter inputs (including one double-edge function)
One clock-synchronous 8-bit serial interface
Comparator (2 channels)
Built-in oscillators
錚?/div>
Main clock: Ceramic or crystal oscillator (an external clock is also possible)
Powered by ICminer.com Electronic-Library Service CopyRight 2003
