Data Sheet
HBT Series 鈥?Half-Brick DC/DC Converter
48V Input
60 Watt Triple Output
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
60 Watts maximum total output power
Three fully isolated outputs 5V/12V/12V
5V output provides up to 12 Amps
(2) 12V outputs each provide up to 2.5 Amps
Excellent cross regulation
Low profile 鈥?12.7 mm
High efficiency topology, 88% Typical
Output overcurrent & overvoltage protection
Overtemperature protection
Set point accuracy
鹵
2.0%
1500V Input/output isolation meets basic
insulation requirements
UL 1950 Recognized, CSA 22.2 No. 950-95
certified; TUV IEC950
Applications
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Distributed power architectures
Data and Telecommunications Equipment
Computer Equipment
Distributed power architectures
LAN/WAN applications
Data processing applications
Description
The HBT17ZGHH DC-DC Converter operates over an input voltage range of 33Vdc to 75Vdc and provides
three isolated output voltages. The 5V output can provide a full 60W (12 Amperes) of output power and each
12V output can provide up to 30W (2.5 Amperes) of output power. The input is fully isolated from each
output and each output is isolated from one another. The isolation of each output provides flexible output
configurations and separate output returns, which are important in preventing cross-interference between
different loads in system applications. The module has a typical full load efficiency of 88%.
The two-board construction optimizes thermal performance. Power devices are connected to an Integrated
Metal Substrate base plate to minimize thermal impedance and a separate control board is physically
isolated from the hotter IMS board. This approach allows for lower average component temperatures on the
control board and increases the overall reliability. The comprehensive standard feature set includes remote
on/off, and output trim.
Selection Chart
Model
Input
voltage
range,
VDC
33-75
Input
current,
max,
ADC
3.0
Output
voltage, VDC
Output
rated
current,
ADC
12/2.5/2.5
Output Ripple
and Noise,
mV p-p
125/150/150
Efficiency
%
HBT060ZGHH-A
5.0/12.2/12.2
88
REV. 10/01
www.power-one.com
Page 1 of 12
