July 2001
HA-5134/883
Precision Quad Operational Amplifier
Description
The HA-5134/883 is a precision quad operational amplifier that
is pin compatible with the OP-400, LT1014, OP11, RM4156,
and LM148 as well as the HA-4741/883. Each amplifier fea-
tures guaranteed maximum values for offset voltage of 350碌V,
offset voltage drift of 2碌V/
o
C (max), and offset current of 75nA
over the full military temperature range while CMRR/PSRR is
guaranteed greater than 94dB and open loop gain is guaran-
teed above 500kV/V from -55
o
C to +125
o
C. Room temperature
specifications exceed these values such as an offset voltage
matching specification between channels of 200碌V (max) at
+25
o
C.
Precision performance of the HA-5134/883 is enhanced by a
noise voltage density of 7nV/鈭欻z at 1kHz (typ), noise current
density of 2pA/鈭欻z at 1kHz and channel separation of 120dB
(min). Each of the four unity gain stable amps on the quad are
electrically isolated, having only supply lines in common and
are fabricated using Dielectric Isolation to insure quality perfor-
mance in the most demanding applications.
The HA-5134/883 is ideal for compact circuits such as instru-
mentation amplifiers, state-variable filters, and low level trans-
ducer amplifiers. Other applications include precision data
acquisition systems, precision integrators, and accurate thresh-
old detectors in designs where board space is a limitation.
Features
鈥?This Circuit is Processed in Accordance to MIL-STD-
883 and is Fully Conformant Under the Provisions of
Paragraph 1.2.1.
鈥?Low Offset Voltage (+25
o
C). . . . . . . . . . . . .200碌V (Max)
(Full Temp.) . . . . . . . . . . . .350碌V (Max)
鈥?Low Offset Voltage Drift at Temp. . . . . . . . 2碌V/
o
C (Max)
鈥?Offset Voltage Match . . . . . . . . . . . . . . . . . .350碌V (Max)
鈥?High Channel Separation . . . . . . . . . . . . . . 120dB (Min)
鈥?Low Noise (f
鈮?/div>
100Hz) . . . . . . . . . . . . . . 10nV/鈭欻z (Max)
鈥?Wide Bandwidth . . . . . . . . . . . . . . . . . . . . . . .4MHz (Typ)
鈥?High CMRR/PSRR . . . . . . . . . . . . . . . . . . . . 100dB (Min)
鈥?High Voltage Gain . . . . . . . . . . . . . . . . . . 800kV/V (Min)
鈥?Dielectric Isolation
Applications
鈥?Instrumentation Amplifiers
鈥?State-Variable Filters
鈥?Precision Integrators
鈥?Threshold Detectors
鈥?Precision Data Acquisition Systems
鈥?Low-Level Transducer Amplifiers
Part Number Information
PART
NUMBER
HA1-5134/883
HA4-5134/883
TEMPERATURE
RANGE
-55
o
C to +125
o
C
-55
o
C to +125
o
C
PACKAGE
14 Lead CerDIP
20 Lead Ceramic LCC
Pinouts
HA-5134/883
(CERDIP)
TOP VIEW
OUT1
-IN1
+IN1
V+
+IN2
-IN2
OUT2
1
2
3
4
5
6
7
+
-2
+
3-
-
+1
-
4+
14
13
12
11
10
9
8
OUT4
-IN4
+IN4
V-
+IN3
-IN3
OUT3
+IN1
NC
V+
NC
+IN2
4
5
6
7
8
9
-IN2
10 11 12 13
OUT2
OUT3
-IN3
NC
2
+ -
3
- +
+ -
1
- +
4
HA-5134/883
(CLCC)
TOP VIEW
OUT1
OUT4
-IN1
-IN4
18 +IN4
17 NC
16 V-
15 NC
14 +IN3
NC
1
3
2
20 19
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 321-724-7143
|
Intersil and Design is a trademark of Intersil Americas Inc.
|
Copyright 漏 Intersil Americas Inc. 2001
Spec Number
1
511033-883
File Number
3713.1
