Timers
Multi-function
Type H 211
鈥?3 selectable functions: - Delay on operate
- Interval timer
- Interval timer with contact
鈥?Time ranges: 0.1 s to 10 h
鈥?Automatic and manual start functions
鈥?Knob-adjustable time within range
鈥?Oscillator-controlled time circuit
鈥?Repeatability deviation:
鈮?/div>
1%
鈥?Output: 5 A SPDT relay
鈥?For mounting on DIN-rail in accordance with
DIN/EN 50 022
鈥?H2 -housing
鈥?LED-indication for relay and power supply on
鈥?AC and DC power supply
Product Description
Multi-function, multi-voltage
time relay with 6 selectable
time ranges up to 10 h and 3
different supply voltages. For
mounting on DIN-rail. Often
used where several modes of
operation are needed for dif-
ferent applications.
Ordering Key
Housing
Type/function
Output
Power supply
H 211 156 230
Type Selection
Plug
For mounting
on DIN-rail
Output
SPDT
Time range
0.1 s - 10 h
Supply: 24 VAC/DC & 230 VAC Supply: 115 VAC
H 211 156 230
H 211 156 115
Time Specifications
Time ranges
0.1 s - 1 s
1s
- 10 s
0.1 m - 1 m
1 m - 10 m
0.1 h - 1 h
1h
- 10 h
-5% +10% on max.
min. actual time
鈮?/div>
min. set time
鈮?/div>
1%
鈮?/div>
0.05%/V
鈮?/div>
0.2%/擄C
Intercon. term. 1 & 2
term. 2 pos., 8 VDC, 2.5 mA
鈮?/div>
10 ms
Min. 200 ms
Output Specifications
Output
Basic electrical insulation
Contact ratings
(AgCdO)
Resistive loads
AC 1
DC 1
Mechanical life
Electrical life
AC 1
Operating frequency
Insulation voltages
Rated insulation voltage
SPDT relay
250 VAC (rms)
(contact/electronics)
碌 (micro gap)
5 A/230 VAC (1200 VA)
5 A/24 VDC (120 W)
鈮?/div>
10 x 10
6
operations
鈮?/div>
10
5
operations (at max. load)
鈮?/div>
7200 operations/h
2.0 kVAC (rms) (cont./elec.)
Time range accuracy
Repeatability deviation
Time variation
Within rated power supply
and ambient temperature
Reset
Time and/or relay
Pulse duration
Power supply interruption
Specifications are subject to change without notice (27.10.99)
