GT28F800B3-T120 Datasheet

  • GT28F800B3-T120

  • SMART 3 ADVANCED BOOT BLOCK WORD-WIDE

  • 426.02KB

  • 49頁

  • INTEL   INTEL

掃碼查看芯片數據手冊

上傳產品規(guī)格書

PDF預覽

E
n
n
n
PRELIMINARY
SMART 3 ADVANCED BOOT BLOCK
WORD-WIDE
4-MBIT (256K X 16), 8-MBIT (512K X 16),
16-MBIT (1024K X 16)
FLASH MEMORY FAMILY
28F400B3, 28F800B3, 28F160B3
Flexible SmartVoltage Technology
錚?/div>
2.7V鈥?.6V Program/Erase
錚?/div>
2.7V鈥?.6V Read Operation
錚?/div>
12V V
PP
Fast Production
Programming
2.7V or 1.8V I/O Option
錚?/div>
Reduces Overall System Power
Optimized Block Sizes
錚?/div>
Eight 4-KW Blocks for Data,
Top or Bottom Locations
錚?/div>
Up to Thirty-One 32-KW Blocks for
Code
High Performance
錚?/div>
2.7V鈥?.6V: 120 ns Max Access Time
Block Locking
錚?/div>
V
CC
-Level Control through WP#
Low Power Consumption
錚?/div>
20 mA Maximum Read Current
Absolute Hardware-Protection
錚?/div>
V
PP
= GND Option
錚?/div>
V
CC
Lockout Voltage
Extended Temperature Operation
錚?/div>
鈥?0擄C to +85擄C
n
n
n
n
n
n
n
n
n
Supports Code Plus Data Storage
錚?/div>
Optimized for FDI, Flash Data
Integrator Software
錚?/div>
Fast Program Suspend Capability
錚?/div>
Fast Erase Suspend Capability
Extended Cycling Capability
錚?/div>
10,000 Block Erase Cycles
Automated Word Program and Block
Erase
錚?/div>
Command User Interface
錚?/div>
Status Registers
SRAM-Compatible Write Interface
Automatic Power Savings Feature
Reset/Deep Power-Down
錚?/div>
1 碌A I
CC
Typical
錚?/div>
Spurious Write Lockout
Standard Surface Mount Packaging
錚?/div>
48-Ball
碌BGA*
Package
錚?/div>
48-Lead TSOP Package
Footprint Upgradeable
錚?/div>
Upgradeable from 2-, 4- and 8-Mbit
Boot Block
ETOX鈩?V (0.4
碌)
Flash Technology
n
n
n
n
n
The new Smart 3 Advanced Boot Block, manufactured on Intel鈥檚 latest 0.4碌 technology, represents a feature-
rich solution at overall lower system cost. Smart 3 flash memory devices incorporate low voltage capability
(2.7V read, program and erase) with high-speed, low-power operation. Several new features have been
added, including the ability to drive the I/O at 1.8V, which significantly reduces system active power and
interfaces to 1.8V controllers. A new blocking scheme enables code and data storage within a single device.
Add to this the Intel-developed Flash Data Integrator (FDI) software and you have the most cost-effective,
monolithic code plus data storage solution on the market today. Smart 3 Advanced Boot Block Word-Wide
products will be available in 48-lead TSOP and 48-ball 碌BGA* packages. Additional information on this
product family can be obtained by accessing Intel鈥檚 WWW page: http://www.intel.com/design/flcomp.
May 1997
Order Number: 290580-002
