352/,1;

鈩?/div>

GS7032

Digital Video Serializer

DATA SHEET

FEATURES

鈥?SMPTE 259M-C compliant (270Mb/s)

鈥?serializes 8-bit or 10-bit data

鈥?minimal external components (no loop filter

components required)

鈥?isolated, dual-output, adjustable cable driver

鈥?3.3V and 5.0V CMOS/TTL compatible inputs

鈥?lock detect indication

鈥?SMPTE scramble and NRZI coding bypass option

鈥?EDH support with GS9001, GS9021 or EDH FPGA code

APPLICATION

SMPTE 259M-C parallel to serial interfaces for video

cameras, VTRs, signal generators; Generic parallel to serial

conversion.

鈥?/div>

DESCRIPTION

The GS7032 is designed to encode and serialize SMPTE

125M bit parallel digital video signals as well as other 8-bit

or 10-bit parallel formats. This device performs the following

functions:

鈥?/div>

sync detection

parallel to serial conversion

data scrambling (using the X

+ X

+ 1 algorithm)

10x parallel clock multiplication

conversion of NRZ to NRZI serial data

GS7032

The GS7032 features 270M/bs data rate with a single VCO

resistor. Other features include a lock detect output, NRZI

encoding and SMPTE scrambler bypass, a sync detect

disable, and an isolated dual output cable driver suitable

for driving 75鈩?loads.

ORDERING INFORMATION

PART NUMBER

PACKAGE

TEMPERATURE

GS7032 - CVM

GS7032 - CTM

44 pin TQFP

44 pin TQFP Tape

0擄C to 70擄C

SYNC DETECT DISABLE (SYNC DIS)

RESET

BYPASS

DATA

(PD0-PD9)

INPUT

LATCH

SYNC

DETECT

PARALLEL

to SERIAL

CONVERTER

NRZ to NRZI

SDO

SERIAL

DIGITAL

OUTPUTS

SMPTE

SCRAMBLER

RESET

BYPASS

CLK

/10

PARALLEL CLOCK

INPUT (PCLKIN)

CLK

LOAD

PLL

LOOP BANDWIDTH

CONTROL (LBWC)

MUTE

LOCK

DETECT

(LOCK DET)

VCO+

VCO-

BLOCK DIAGRAM

Revision Date: June 2001

GENNUM CORPORATION P.O. Box 489, Stn. A, Burlington, Ontario, Canada L7R 3Y3

Tel. +1 (905) 632-2996 Fax. +1 (905) 632-5946 E-mail: info@gennum.com

www.gennum.com

Document No. 14583 - 02
