GS1524 HD-LINX鈩?II

Multi-Rate SDI Adaptive

Cable Equalizer

GS1524 Data Sheet

Key Features

鈥?/div>

SMPTE 292M, SMPTE 344M and SMPTE 259M

compliant

automatic cable equalization

multi-standard operation from 143Mb/s to

1.485Gb/s

supports DVB-ASI at 270Mb/s

manual bypass (useful for low data rates with slow

rise/fall times)

performance optimized for 270Mb/s and 1.485Gb/s

typical maximum equalized length of Belden 1694A

cable: 140m at 1.485Gb/s, 350m at 270Mb/s

50惟 differential output (with internal 50惟 pull-ups)

Pb-free and RoHS Compliant

Description

The GS1524 is a second-generation high-speed bipolar

integrated circuit designed to equalize and restore

signals received over 75惟 co-axial cable at data rates

from 143Mb/s up to 1.485Gb/s. The GS1524 is

designed to support SMPTE 292M, SMPTE 344M and

SMPTE 259M, and is optimized for performance at

270Mb/s and 1.485Gb/s.

The GS1524 features DC restoration to compensate for

the DC content of SMPTE pathological test patterns.

The GS1524 also incorporates a Cable Length Indicator

(CLI) that provides an indication of the amount of cable

being equalized for data rates up to 360Mb/s.

A voltage programmable mute threshold (MCLADJ) is

included to allow muting of the GS1524 output when an

approximate selected cable length is reached for

SMPTE 259M signals. This feature allows the GS1524

to distinguish between low amplitude SD-SDI signals

and noise at the input of the device. The CD/MUTE pin

provides an indication of the GS1524 mute status in

addition to functioning as a mute control input. The SD

outputs of the GS1524 may be forced to a mute state by

applying a voltage to the CD/MUTE pin.

Power consumption is typically 265mW using a 3.3V

power supply.

This component and all homogeneous subcomponents

are RoHS compliant.

Key Specifications

鈥?/div>

cable length indicator for SMPTE 259M inputs

output mute based on max cable length adjust or

manual override

single 3.3V power supply operation

operating temperature range: 0擄C to +70擄C

Applications

鈥?/div>

SMPTE 292M, SMPTE 344M and SMPTE 259M

Coaxial Cable Serial Digital Interfaces

MCLADJ

CABLE LENGTH INDICATOR/ADJUSTOR

CARRIER DETECT

MUTE

CLI

CD/MUTE

BYPASS

SDI

EQUALIZER

DC RESTORE

OUTPUT

SDO

AGC

Functional Block Diagram

14976 - 7

June 2005

1 of 18

www.gennum.com
