GM71C17800C

GM71CS17800CL

2,097,152 WORDS x 8 BIT

CMOS DYNAMIC RAM

Description

The GM71C(S)17800C/CL is the new

generation dynamic RAM organized 2,097,152

x 8 bit. GM71C(S)17800C/CL has realized

higher density, higher performance and various

functions by utilizing advanced CMOS process

technology. The GM71C(S)17800C/CL offers

Fast Page Mode as a high speed access mode.

Multiplexed address inputs permit the

GM71C(S)17800C/CL to be packaged in

standard 400 mil 28pin plastic SOJ, and standard

400mil 28 pin plastic TSOP II. The package size

provides high system bit densities and is

compatible with widely available automated

testing and insertion equipment.

Features

* 2,097,152 Words x 8 Bit Organization

* Fast Page Mode Capability

* Single Power Supply (5V+/-10%)

* Fast Access Time & Cycle Time

(Unit: ns)

t

RAC

t

CAC

GM71C(S)17800C/CL-5

GM71C(S)17800C/CL-6

GM71C(S)17800C/CL-7

50

60

70

13

15

18

t

RC

90

110

130

t

PC

35

40

45

* Low Power

Active : 715/660/605mW (MAX)

Standby : 11mW (CMOS level : MAX)

0.83mW (L-version : MAX)

* RAS Only Refresh, CAS before RAS Refresh,

Hidden Refresh Capability

* All inputs and outputs TTL Compatible

* 2048 Refresh Cycles/32ms

* 2048 Refresh Cycles/128ms (L- version)

* Battery Back Up Operation (L- version)

* Self Refresh Operation (L-version)

Pin Configuration

28 SOJ

V

SS 1

I/O0

2

I/O1

3

I/O2

4

I/O3

5

WE

6

RAS

7

NC

8

A10

9

A0

10

A1

11

A2

12

A3

13

V

CC 14

28

V

SS

27

I/O7

26

I/O6

25

I/O5

24

I/O4

23

CAS

22

OE

21

A9

20

A8

19

A7

18

A6

17

A5

16

A4

15

V

SS

28 TSOP II

V

SS 1

I/O0

2

I/O1

3

I/O2

4

I/O3

5

WE

6

RAS

7

NC

8

28

V

SS

27

I/O7

26

I/O6

25

I/O5

24

I/O4

23

CAS

22

OE

21

A9

20

A8

19

A7

18

A6

17

A5

16

A4

15

V

SS

A10

9

A0

10

A1

11

A2

12

A3

13

V

CC 14

(Top View)

Rev 0.1 / Apr鈥?1
