GM71C(S)17403C/CL

4,194,304 WORDS x 4 BIT

CMOS DYNAMIC RAM

Description

The GM71C(S)17403C/CL is the new

generation dynamic RAM organized 4,194,304

words x 4 bit. GM71C(S)17403C/CL has

realized higher density, higher performance and

various functions by utilizing advanced CMOS

process technology. The GM71C(S)17403C/CL

offers Extended Data Out (EDO) Mode as a

high speed access mode. Multiplexed address

inputs permit the GM71C(S)17403C/CL to be

packaged in a standard 300 mil 24(26) pin SOJ

and a standard 300mil 24(26) pin plastic TSOP

II. The package size provides high system bit

densities and is compatible with widely

available automated testing and insertion

equipment. System oriented features include

single power supply 5V+/-10% tolerance, direct

interfacing capability with high performance

logic families such as Schottky TTL.

Features

* 4,194,304 Words x 4 Bit Organization

* Extended Data Out Mode Capability

* Single Power Supply (5V+/-10%)

* Fast Access Time & Cycle Time

(Unit: ns)

t

RAC

t

CAC

GM71C(S)17403C/CL-5

GM71C(S)17403C/CL-6

GM71C(S)17403C/CL-7

50

60

70

13

15

18

t

RC

84

104

124

t

HPC

20

25

30

Pin Configuration

24(26) SOJ

V

CC

I/O1

I/O2

WE

RAS

NC

A10

A0

A1

A2

A3

V

CC

1

2

3

4

5

6

26

25

24

23

22

21

* Low Power

Active : 660/605/550mW (MAX)

Standby : 11mW (CMOS level : MAX)

: 0.83mW (L-version : MAX)

* RAS Only Refresh, CAS before RAS Refresh,

Hidden Refresh Capability

* All inputs and outputs TTL Compatible

* 2048 Refresh Cycles/32ms

* 2048 Refresh Cycles/128ms (L-version)

* Battery Backup Operation (L-version)

* Test Function : 16bit parallel test mode

24(26) TSOP II

V

SS

I/O4

I/O3

CAS

OE

A9

A8

A7

A6

A5

A4

V

SS

V

CC

I/O1

I/O2

WE

RAS

A11

A10

A0

A1

A2

A3

V

CC

1

2

3

4

5

6

26

25

24

23

22

21

V

SS

I/O4

I/O3

CAS

OE

A9

A8

A7

A6

A5

A4

V

SS

8

9

10

11

12

13

19

18

17

16

15

14

8

9

10

11

12

13

19

18

17

16

15

14

(Top View)

Rev 0.1 / Apr鈥?1
